3.9 Connection of DECT Portable Stations
182 Installation Manual
3.9.8 Wall Mounting
Mounting the KX-TDA0158CE
1. Place the reference for wall mounting (KX-TDA0158CE) on the wall to mark the 2 screw positions.
2. Install the 2 screws and washers (included) into the wall.
Notes
• Make sure that the screw heads are at the same distance from the wall.
• Install the screws perpendicular to the wall.
3. Hook the CS on the screw heads.
CAUTION
Make sure the cables are securely fastened to the wall.
To Next Page
