Panasonic KX-TG6841B

46
KX-TG6841B/KX-TG6842B/KX-TG6843B/KX-TG6844B/KX-TG6845B/KX-TG6873B/KX-TGA680B
11 Disassembly and Assembly Instructions
11.1. Disassembly Instructions
11.1.1. Base Unit
Cabinet cover
Solders
5 screws
Main P.C. board
Pararell wire
Ԙ
Remove the 5 screws to remove
the cabinet cover.
ԙ
Remove the solders.
Ԛ
Remove the pararell wire
to remove the main P.C. board.
