16.5.2. Handset
16.5.2.1. Cabinet and Electrical Parts
16.5.2.2. Main P.C. Board Parts
Note:
(*1) Reconfirm the model No. written on the handset's name
plate when replacing PCB100. Because the model No. of
the optional handset may differ from the included handset.
(*2) When replacing IC3 or X1, make the adjustment
using PNZZTG6841M. Refer to Handset (P.60) of Things
to Do after Replacing IC or X'tal.
(*3) When replacing the handset LCD, See How to
Replace the Handset LCD (P.52).
Safety Ref.
No.
Part No. Part Name & Description Remarks
101 PNGP1272Z1 PANEL, LCD PMMA-HB
102 PNYE1106Z TAPE, DOUBLE SIDED
103 PNKM1467Z1 CABINET BODY ABS-HB
104 L0AD01A00026 RECEIVER
105 PNYE1107Z SPACER, CUSHION LCD
106 PNBC1483Z1 BUTTON, NAVIGATOR KEY ABS-HB
107 PNJK1181Z KEYBOARD SWITCH
108 PNHR1757Z GUIDE, SPEAKER ABS-HB
109 PQHG10729Z RUBBER PARTS, RECEIVER
110 L0AA02A00120 SPEAKER
111 PNHS1502Z SPACER, SPEAKER NET
112 PNKE1269Z1 COVER, EP CAP
113 PNJC1018Z BATTERY TERMINAL
114 PNKF1271Z1 CABINET COVER ABS-HB
115 PNGT7140Z NAME PLATE
116 PNQT2006Z LABEL, ATTENTION
117 PNQT2629Z LABEL, BATTERY
118 PNHS1466Z SPACER, BATTERY
119 PNKK1076Z1 LID, BATTERY ABS-HB
120 PNYNTGA680BR LID, BATTERY ASS'Y ABS-HB
121 PNHR1644Z SPA C E R PS-H B
Safety Ref.
No.
Part No. Part Name & Description Remarks
PCB100 PNWP1TGA680R MAIN P.C.BOARD ASS'Y
(RTL) (*1)
(ICs)
IC1 C2HBCY000124 IC
IC3 PNWITGA680R IC(EEPROM)(*2)
IC4 C0DBZYY00357 IC
(TRANSISTORS)
Q2 B1ADCF000040 TRANSISTOR(SI)
Q3 B1ABGE000011 TRANSISTOR(SI)
Q4 B1ADCF000040 TRANSISTOR(SI)
Q6 DRC9113Z0L TRANSISTOR(SI)
Q9 2SC6054JSL TRANSISTOR(SI) S
Q10 B1ADNB000003 TRANSISTOR(SI)
Q11 2SC6054JSL TRANSISTOR(SI) S
Q12 B1ADCF000040 TRANSISTOR(SI)
(DIODES)
D1 3 B 0 B C 4 R 3 A0 00 6 DIO DE (S I)
D1 4 B 0 B C 4 R 3 A0 00 6 DIO DE (S I)
(LEDS)
LED1 B3ACB0000190 LED
LED2 B3ACB0000190 LED
LED3 B3ACB0000190 LED
LED4 B3ACB0000190 LED
LED5 B3ACB0000190 LED
LED6 B3ACB0000190 LED
LED20 B3AFB0000561 LED
(COIL)
L801 G1C2N7Z00009 COIL
(RESISTOR ARRAYS)
RA2 D1H83314A013 RESISTOR ARRAY S
RA3 EXB24V331J RESISTOR ARRAY
RA4 EXB24V332JX RESISTOR ARRAY
RA5 EXB28V332JX RESISTOR ARRAY
(IC FILTER)
L3 J0JDC0000045 IC FILTER
(RESISTORS)
R2 D0GA303JA021 30k
R3 D0GA152JA021 1.5k
R4 D0GA473JA021 47k
R6 D0GA103JA021 10k
R7 D0GA104JA021 100k
R8 ERJ8GEYJ4R3V 4.3 S
R9 D0GA303JA021 30k
R10 ERJ3GEYJ1R0 1 S
R11 D0GA681JA021 680
R12 D0GA183JA015 18k
R13 D0GA103JA021 10k
R19 ERJ2RKF2003X 200k S
R20 ERJ2RKF1003X 100k S
R21 D0GA104JA021 100k
R22 D0GA332JA015 3.3k
R23 ERJ2GEYJ391 390 S
R24 ERJ2GEJ100 10 S
R25 D0GA222JA021 2.2k
R26 D0GA332JA015 3.3k
R27 D0GA222JA021 2.2k
R28 D0GA222JA021 2.2k
R31 ERJ2RKF1003X 100k S
R32 D0GA104JA021 100k
R33 ERJ2RKF1003X 100k S
R34 ERJ2GEYJ391 390 S
R45 D0GBR10JA113 0.1
R66 D0GA103JA021 10k
R67 D0GA103JA021 10k
R68 D0GA103JA021 10k
R69 D0GA103JA021 10k
R70 D0GA101JA021 100
R72 ERJ2GE0R00 0 S
L8 ERJ2GEJ100 10 S
(CAPACITORS)
C2 F1J0J2260002 22
C3 F1J0J2260002 22
C5 ECUE1A104KBQ 0.1
C6 ECUE1A104KBQ 0.1
C11 ECUE1A104KBQ 0.1
C12 ECJ1VB0G106M 10 S
C13 ECUE1A104KBQ 0.1
C14 ECUV1C393KBV 0.039
C15 ECUE1H390JCQ 39p
C16 F1J0J2260002 22
C17 ECUE1H100DCQ 10p
C18 ECUE1H100DCQ 10p
C20 ECJ1VB0G106M 10 S
C21 ECUE0J105KBQ 1
C22 ECUE1A104KBQ 0.1
C23 ECUE1A104KBQ 0.1
C24 ECUE0J105KBQ 1
C25 ECUV1A225KBV 2.2 S
C26 ECJ1VB0G106M 10 S
C27 ECUE1H102KBQ 0.001 S
C29 ECUE0J105KBQ 1
C30 ECUE0J105KBQ 1
C31 ECJ1VB0G106M 10 S
C32 ECUE0J105KBQ 1
C33 ECUE1A104KBQ 0.1
C34 ECUE1H390JCQ 39p
C36 ECUE1A104KBQ 0.1
C37 ECJ1VB0G106M 10 S
C40 ECUE1A104KBQ 0.1
C41 ECUE1A104KBQ 0.1
C43 ECUE1A104KBQ 0.1
C44 ECUE0J105KBQ 1
C45 ECUE1A104KBQ 0.1
Safety Ref.
No.
Part No. Part Name & Description Remarks
