16.5.1.3. Operational P.C. Board Parts
16.5.1.4. LED Board Parts
R133 ERJ3GEYJ334 330k S
R141 D0GB104JA057 100k
R142 PQ4R18XJ272 2.7k S
R145 D0GA222JA021 2.2k
R151 D0GA104JA021 100k
R152 ERJ2GEJ134X 130k S
R160 ERJ3GEYJ821 820 S
R161 D0GB104JA057 100k
R162 D0GB473JA057 47k
R163 D0GG390JA007 39
R164 D0GB272JA057 2.7k
R165 ERJ3GEYJ273 27k S
R168 ERJ3GEYJ472 4.7k S
R171 D0GA221JA021 220
R172 ERJ2GEJ684 680k
R175 D0GA392JA015 3.9k
R176 D0GA102JA021 1k
R177 D0GA102JA021 1k
R321 ERJ2RKF1400 140
R322 ERJ2RKF1000 100
R331 ERJ2RKF6802 68k
R332 ERJ2RKF3302 33k
R351 D0GA333JA015 33k
R352 D0GA682JA021 6.8k
R354 D0GA123JA021 12k
R355 D0GA681JA021 680
R371 ERJ8GEYJ1R0 1
R372 ERJ8GEYJ1R0 1
R373 D0GA681JA021 680
R451 ERJ2GEYJ391 390 S
R501 D0GB100JA057 10
R502 D0GA103JA021 10k
R503 D0GA103JA021 10k
R504 D0GA103JA021 10k
R506 D0GA103JA021 10k
R651 D0GA681JA021 680
R652 D0GA681JA021 680
R654 D0GA681JA021 680
R661 ERJ3GEYJ390 39
R665 D0GA821JA021 820
R701 D0GA332JA015 3.3k
R702 D0GA102JA021 1k
R891 ERJ2GEJ471 470 S
R892 ERJ2GEJ471 470 S
(CAPACITORS)
C101 F1K2H681A008 680p S
C102 F1K2H681A008 680p S
C111 F1J2A473A024 0.047
C112 F1J2A473A024 0.047
C113 PQCUV1A684KB 0.68
C120 ECUE1H102KBQ 0.001 S
C121 F1K2H681A008 680p S
C122 F1K2H681A008 680p S
C132 ECUV1H103KBV 0.01
C142 ECUV1H103KBV 0.01
C152 ECUE1C103KBQ 0.01
C161 F1K1E1060001 10
C167 ECUV1H102KBV 0.001
C171 ECUV1C223KBV 0.022
C173 ECUE1A104KBQ 0.1
C175 ECUE1H561KBQ 560p S
C176 ECUV1C105KBV 1
C178 ECUV1C333KBV 0.033
C184 ECUV1C105KBV 1
C321 ECUV1C105KBV 1
C341 F2G0J102A148 1000
C342 ECUE1A104KBQ 0.1
C344 F2G0J102A148 1000
C351 ECUV1C105KBV 1
C451 PQCUV0J106KB 10 S
C457 ECUE1C333KBQ 0.033 S
C458 ECUE1C333KBQ 0.033 S
C459 ECUE1H102KBQ 0.001 S
Safety Ref.
No.
Part No. Part Name & Description Remarks
C501 ECUE1A104KBQ 0.1
C502 ECJ1VB0G106M 10 S
C503 ECJ1VB0G106M 10 S
C504 ECUE0J105KBQ 1
C505 ECJ1VB0G106M 10 S
C506 ECUE0J105KBQ 1
C507 ECUV0J225KBV 2.2
C508 ECUE1H100DCQ 10p
C509 ECUE1H120JCQ 12p
C510 ECUE0J105KBQ 1
C511 ECJ1VB0G106M 10 S
C513 ECUV0J225KBV 2.2
C515 ECUE0J105KBQ 1
C516 ECUE1A104KBQ 0.1
C517 ECUE1A104KBQ 0.1
C518 ECUE1A104KBQ 0.1
C519 ECUE1A104KBQ 0.1
C520 ECUE1A104KBQ 0.1
C521 ECUE0J105KBQ 1
C601 ECUE1A104KBQ 0.1
C611 ECUE1A104KBQ 0.1
C661 ECUE1A104KBQ 0.1
C819 ECUE1H100DCQ 10p
C871 F1G1H1R5A765 1.5p
C872 F1G1H1R3A765 1.3p
C873 F1G1H2R0A765 2p
C874 ECUE1H150JCQ 15p S
C891 F1G1H5R0A765 5p
C892 F1G1H5R0A765 5p
C893 ECUE1H100DCQ 10p
C894 ECUE1H100DCQ 10p
C895 F1G1H2R0A765 2p
(OTHERS)
E1 L5DYAYY00004 LIQUID CRYSTAL DISPLAY
(*2)
E2 PNHR1762Z TRANSPARENT PLATE, LCD PMMA-HB
E3 PNHX1617Z COVER, REFLECTOR SHEET
E4 PNHR1761Z GUIDE, LCD ABS-HB
P101 D4DAY220A022 THERMISTOR (POSISTOR)
F301 K5H302Y00003 FUSE
X501 H0J138500011 CRYSTAL OSCILLATOR (*1)
Safety Ref.
No.
Part No. Part Name & Description Remarks
PCB2 PNWP2TG6841H OPERATIONAL P.C.BOARD
ASS'Y (RTL)
(LEDS)
LED901 B3AAB0000347 LED
LED902 B3AAB0000347 LED
LED904 B3AAB0000347 LED
(RESISTOR)
R906 EREJ3GEYJ330 33 S
(CAPACITORS)
C901 ECUE0J105KBQ 1
C902 ECUV1C105KBV 1
C912 ECUE1H100DCQ 10p
(OTHER)
MIC1 L0CBAY000123 MICROPHONE
Safety Ref.
No.
Part No. Part Name & Description Remarks
(LED)
WLED B3AFB0000370 LED
Safety Ref.
No.
Part No. Part Name & Description Remarks
