Panasonic KX-TGC220AL - Disassembly and Assembly Instructions; Disassembly Instructions; Base Unit

44
KX-TGC220/KX-TGC222/KX-TGC223/KX-TGCA20
10 Disassembly and Assembly Instructions
10.1. Disassembly Instructions
10.1.1. Base Unit
10.1.1.1. KX-TGC220
ձ
Remove the 2 screws to remove
the cabinet cover.
ղ
Remove the solders.
ճ
Remove the main P.C. board.
ճ
Main P.C. board
ձ
4 screws
Solders
ղ
