85
KX-TGC220/KX-TGC222/KX-TGC223/KX-TGCA20
15.5.2.2. Main P.C.Board Parts
Note:
(*1) Reconfirm the model No. written on the handset’s name
plate when replacing PCB100. Because the model No. of
the optional handset may differ from the included handset.
(*2) When replacing IC4 or X1, make the adjustment
using PNZZTGC220NZ, PNZZTGC220AL, Refer to How to
download the data (P.55) of Things to Do after
Replacing IC or X'tal (P.55)
(*4) When replacing the handset LCD, See How to
Replace the Handset LCD (P.48).
(*5) Backside of this IC has a ground plate. Refer to How to
Replace the Flat Package IC (P.59).
(*6) Supplied IC is Flat Package Type.
15.5.3. Charger Unit
15.5.3.1. Cabinet and Electrical Parts
15.5.4. Accessories and Packing Materials
Safety Ref.
No.
Part No. Part Name & Description Remarks
PCB100 PNWP1CA20AZR MAIN P.C.BOARD ASS'Y
(RTL) (*1)
(ICs)
IC1 C1CB00003837 IC(*5)(*6)
IC4 C3FBLY000162 IC(*2)
IC7 PNWIGCA20EXR IC (EEPROM)(*2)
(TRANSISTORS)
Q1 B1ADGE000012 TRANSISTOR(SI)
Q2 B1ADCF000040 TRANSISTOR(SI)
Q3 B1ABGE000011 TRANSISTOR(SI)
Q4 B1ADCF000040 TRANSISTOR(SI)
Q6 2SC6054JSL TRANSISTOR(SI) S
Q9 UNR9216J0L TRANSISTOR(SI) S
(DIODES)
LED7 B3ACB0000190
D I O D E ( S I )
LED8 B3ACB0000190 D I O D E ( S I )
LED9 B3ACB0000190 D I O D E ( S I )
(RESISTOR ARRAYS)
RA1 EXB28V271JX RESISTOR ARRAY
RA5 EXB28V332JX RESISTOR ARRAY
RA7 EXB24V821JX RESISTOR ARRAY
(RESISTORS)
R1 ERJ2GEJ103 1 0 k S
R2 ERJ2GEJ303 3 0 k S
R6 ERJ2GEJ103 1 0 k S
R7 ERJ2GEJ821 820 S
R8 ERJ8GEYJ4R3V 4.3 S
R9 ERJ2GEJ303 3 0 k S
R15 D0GA152JA021 1 . 5 k S
R20 D0GA563ZA006 5 6 k
R23 ERJ2GEJ102 1 k S
R45 D0GBR10JA113
0.1
R51 ERJ2GEJ103 1 0 k S
R52 ERJ2GEJ103 1 0 k S
R53 ERJ2GEJ332 3 . 3 k S
R54 ERJ2GEJ331 330 S
R55 ERJ2GEJ331 330 S
R61 ERJ2GEJ102 1 k S
R76 ERJ2GEJ1R0 1 S
R77 ERJ2GEJ1R0 1 S
(CAPACITORS)
C1 EEE0JA221WP 220
C5 ECUV1C104KBV 0.1
C6 ECUV1C104KBV 0.1
C11 ECUE1A104KBQ 0.1
C12 ECUV0J225KBV 2.2
C13 ECUE1A104KBQ 0.1
C15 ECUE1H390JCQ 3 9 p
C19 ECUE1H102KBQ 0.001
C22 ECUE0J105KBQ
1
C29 ECUE0J105KBQ 1
C30 ECUV1A105KBV 1
C36 ECUE1H390JCQ 3 9 p
C41 ECUE1A104KBQ 0.1
C43 ECUE1H100DCQ 1 0 p
C44 ECUE1A104KBQ 0.1
C45 ECUE1A104KBQ 0.1
C46 ECUE1H100DCQ 1 0 p
C47 ECUE0J105KBQ 1
C52 ECUE0J105KBQ 1
C53 ECUV1A225KBV 2.2
C55 ECUE1H100DCQ 1 0 p
C56 ECUE0J105KBQ 1
C57 ECUE1A104KBQ 0.1
C59 ECUE0J105KBQ 1
C69 ECUE1A104KBQ 0.1
C70 ECUE1H680JCQ 6 8 p
C71 ECUE1H680JCQ 6 8 p
C78 ECUE1H222KBQ 0.0022
C79 ECUE1H222KBQ 0.0022
C91 ECUV1C105KBV 1
C92 ECUV1C105KBV
1
C93 ECUV1C105KBV 1
C94 ECUV1C105KBV 1
C95 ECUV1C105KBV 1
C96 ECUE0J105KBQ 1
C98 ECUE1H100DCQ 1 0 p
C99 ECUE1H100DCQ 1 0 p
C190 ECUE1A104KBQ 0.1
C191 ECUE0J105KBQ 1
C859 ECUE1H100DCQ 1 0 p
C860 F1G1H1R1A765 CERAMIC CAPACITOR
C862 F1G1H1R5A765 CERAMIC CAPACITOR
C863 F1G1H1R8A765 CERAMIC CAPACITOR
C866 ECUE1A104KBQ 0.1
(OTHERS)
E101 L5DYBYY00067 LIQUID CRYSTAL DISPLAY
(*4)
E102 PNHR1950Z PLATE, LCD
E103 PNHX1761Z C O V E R , L C D
E104 PNHR1949Z GUIDE, LCD
E105 PNJT1142Z CHARGE TERMINAL (L)
E106 PNJT1143Z CHARGE TERMINAL (R)
E107 PNVE1015Z BATTERY TERMINAL
E108 PQHG10729Z RUBBER PARTS
F1 K5H252Y00002 F U S E
MIC100 L0CBAY000053 BUILTIN -MICROPHONE
X1 H0J103500039 CRYSTAL OSCILLATOR (*2)
ZA1 PNMC1091Z MAGNETIC,
SHIELD
Safety Ref.
No.
Part No. Part Name & Description Remarks
200 PNLC1042ZS CHARGER UNIT ASS'Y
without NAME PLATE
(RTL)
200-1 PNKM1479Y2 CABINET BODY PS-HB
200-2 PNJT1148Z CHARGE TERMINAL
200-3 PNKF1280Z4 CABINET COVER PS-HB
200-4 PQHA10023Z RUBBER PARTS, FOOT
CUSHION
200-5 PNJJ021001Z JACK, MODULAR
Safety Ref.
No.
Part No. Part Name & Description Remarks
A1 PNLV226AL0Z AC ADAPTOR (for Base
Unit)
A2 PNLV233ALKZ AC ADAPTOR (for Charger
Unit)
A3 PQJA10168Z CORD, TELEPHONE (for
Australia)
A4 PNJA1037Z CORD, TELEPHONE (for
New Zealand)
Safety Ref.
No.
Part No. Part Name & Description Remarks
To Next Page
