Preparations
Charging battery
Charging the battery
We recommend charging in a location where the ambient temperature is between 10 °C
and 30 °C (50 °F to 86 °F) (same for the battery temperature).
Insert the battery into the camera.
Make sure that the camera is turned off.
The battery can be charged from an outlet or through a PC.
USB connection cable (supplied)
AC adaptor (supplied)
Computer
Getting ready: Turn on the computer.
To the electrical outlet
When charging the camera, connect the USB connection cable (supplied) to the
[USB/CHARGE] socket.
[USB/CHARGE] socket
• This terminal is located at the bottom when the camera is in
an upright position.
• Always check the direction of the pins and hold the plug
straight to insert or remove it. (If the cable is inserted in the
wrong direction, the pins could become deformed and cause
faulty operation.)
Also, do not insert into the wrong socket. Doing so may cause
damage to this unit.

Panasonic LUMIX DC-FZ80 Specifications

General

Megapixel	18.9 MP
Camera type	Bridge camera
Sensor type	MOS
Image stabilizer	Yes
Image sensor size	1/2.3 \
Image formats supported	JPEG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4896 x 3672 pixels
Still image resolution(s)	4896 x 3672
Bluetooth	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Night
Photo effects	-
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modes	Aperture priority, Manual, Program, Shutter priority
Self-timer delay	2, 10 s
Digital zoom	4 x
Optical zoom	60 x
Number of aspheric elements	6
Lens structure (elements/groups)	14/12
Maximum focal length (35mm film equiv)	215 mm
Normal focusing range (tele)	- m
Product color	Black
Light metering	Centre-weighted, Spot
ISO sensitivity	80, 3200
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	3200
ISO sensitivity (min)	80
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	895 mAh
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1.5 - 6.1 m
Flash range (wide)	0.3 - 14.1 m
Shoe mounting point type	Hot shoe
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Video formats supported	AVCHD, MP4
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC
Resolution at capture speed	640x480@30fps, 1920x1080@30fps, 1920x1080@60fps, 3840x2160@30fps
Compatible memory cards	SD, SDHC, SDXC
Display diagonal	3 \
Display resolution (numeric)	1040000 pixels
Viewfinder type	Electronic
USB version	2.0
USB connector	Micro-USB B
HDMI connector type	Micro
Cables included	AC

Weight and Dimensions

Depth	119.2 mm
Width	130.2 mm
Height	94.3 mm
Weight	616 g
