304
DVQP1223
Others
Usage cautions and notes
Caring for your camera
To clean your camera, remove the battery, the DC coupler (optional) or a card, or
disconnect the power plug from the outlet, and wipe with a soft, dry cloth.
Use a damp cloth to remove stubborn stains, before wiping with a dry cloth.
Do not use benzine, thinners, alcohol, or kitchen detergent, as these may damage the
outer casing and finish of the camera.
If using a chemically-treated cloth, read the supplied instructions carefully.
When not using for a while
Turn off the camera before removing battery and card (ensure that battery is removed
to prevent damage through over-discharge).
Do not leave in contact with rubber or plastic bags.
Store together with a drying agent (silica gel) if leaving in drawer, etc. Store batteries in
cool (15 °C to 25 °C (59 °F to 77 °F)) places with low humidity (40%RH to 60%RH) and
no major temperature changes.
Charge battery once per year and use completely before storing again.
Check all the parts before taking pictures when you have not used the camera for a
long period of time.
Monitor/viewfinder
Do not press hard on the monitor. This may cause uneven display and damage the
monitor.
In cold climates or other situations when the camera becomes cold, the monitor or
the viewfinder may appear slightly darker than normal immediately after the camera is
turned on. Normal brightness will return once the internal components have warmed up.
The monitor and viewfinder are made with extremely high precision technology.
However there may be some dark or bright spots (red, blue or green) on the screen.
This is not a malfunction. The monitor and viewfinder screens are controlled with
extremely high precision, but some pixels may be inactive. The spots will not be
recorded on pictures on a card.

Table of Contents

Other manuals for Panasonic LUMIX DC-FZ80

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic LUMIX DC-FZ80 and is the answer not in the manual?

Panasonic LUMIX DC-FZ80 Specifications

General IconGeneral
Megapixel18.9 MP
Camera typeBridge camera
Sensor typeMOS
Image stabilizerYes
Image sensor size1/2.3 \
Image formats supportedJPEG, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4896 x 3672 pixels
Still image resolution(s)4896 x 3672
BluetoothNo
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modesNight
Photo effects-
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modesAperture priority, Manual, Program, Shutter priority
Self-timer delay2, 10 s
Digital zoom4 x
Optical zoom60 x
Number of aspheric elements6
Lens structure (elements/groups)14/12
Maximum focal length (35mm film equiv)215 mm
Normal focusing range (tele)- m
Product colorBlack
Light meteringCentre-weighted, Spot
ISO sensitivity80, 3200
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)3200
ISO sensitivity (min)80
Light exposure controlProgram AE
Light exposure correction± 5EV (1/3EV step)
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/16000 s
Slowest camera shutter speed60 s
Power source typeBattery
Battery voltage7.2 V
Battery capacity895 mAh
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)1.5 - 6.1 m
Flash range (wide)0.3 - 14.1 m
Shoe mounting point typeHot shoe
Video resolutions640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Video formats supportedAVCHD, MP4
Maximum video resolution3840 x 2160 pixels
Analog signal format systemNTSC
Resolution at capture speed640x480@30fps, 1920x1080@30fps, 1920x1080@60fps, 3840x2160@30fps
Compatible memory cardsSD, SDHC, SDXC
Display diagonal3 \
Display resolution (numeric)1040000 pixels
Viewfinder typeElectronic
USB version2.0
USB connectorMicro-USB B
HDMI connector typeMicro
Cables includedAC
Weight and Dimensions IconWeight and Dimensions
Depth119.2 mm
Width130.2 mm
Height94.3 mm
Weight616 g
