188
Using Menu Functions
Menu list
[Custom] → [Monitor / Display]
[Histogram]
Enabling/disabling the histogram display.
When set to [ON], you can move the display position of the histogram by pressing .
Direct touch operation is also possible from the recording screen.
Displays distribution of brightness in picture – e.g.
if the graph peaks at the right, this means there are
several bright areas in the picture. A peak in the centre
represents correct brightness (correct exposure). This
can be used as a reference for exposure correction, etc.
(Example)
Dark ← OK → Bright
When the histogram is not the same as that of the recorded picture under the following
conditions, histogram will be displayed in orange:
During Exposure Compensation.
When the flash fires.
When the correct exposure is not achieved, such as when the lighting is low.
[Guide Line]
Sets the pattern of the guidelines to be displayed while recording.
When you select [ ], you can move the position of the guideline by pressing .
You can also set the position directly by touching [ ] on the guideline of the recording screen.
The guideline is not displayed during panorama picture recording.
[Center Marker]
A cross [+] is displayed to indicate the centre of the recording screen. This is useful for
zooming while keeping the subject at the centre of the screen.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DC-TZ200D and is the answer not in the manual?

Panasonic Lumix DC-TZ200D Specifications

General IconGeneral
Megapixel20.1 MP
Camera typeCompact camera
Sensor typeMOS
Image stabilizerYes
Total megapixels20.9 MP
Image sensor size1 \
Image formats supportedJPEG, RAW
Maximum image resolution5472 x 3648 pixels
Still image resolution(s)4864x3648, 3456x2592, 2432x1824, 5472x3648, 3888x2592, 2736x1824, 5472x3080, 3840x2160, 1920x1080, 3648x3648, 2592x2592, 1824x1824
Product colorBlack
Digital zoom4 x
Optical zoom15 x
Focal length range8.8 - 132 mm
Maximum aperture number6.4
Minimum aperture number3.3
Lens structure (elements/groups)13/11
Focus-
Normal focusing range (tele)1 m
Normal focusing range (wide)0.5 m
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/16000 s
Slowest camera shutter speed60 s
Viewfinder screen size0.21 \
Scene modesFood, Handheld night scene, Monochrome, Portrait, Sunset
White balanceArea white balance, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playbackHighlights, Movie, Single image, Slide show, Thumbnails
Self-timer delay2, 10 s
Image quality adjustmentContrast, Saturation, Sharpness
On Screen Display (OSD) languagesDEU, ENG, ESP, FRE, ITA, JPN
Video formats supportedAVCHD, MP4
Maximum video resolution3840 x 2160 pixels
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity80, 100, 125, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)25600
ISO sensitivity (min)80
Light exposure correction± 5EV (1/3EV step)
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.2
Field of view100 %
Display diagonal3 \
Display resolution1840 dot
Display diagonal (metric)7.5 cm
Flash modesAuto, Forced off, Forced on, Slow synchronization
Flash range (tele)1 - 3.9 m
Flash range (wide)0.6 - 6.8 m
Compatible memory cardsSD, SDHC, SDXC
USB version2.0
USB connectorMicro-USB B
HDMI connector typeMicro
Battery voltage7.2 V
Battery capacity1025 mAh
Quantity per pack1 pc(s)
Cables includedUSB
Weight and Dimensions IconWeight and Dimensions
Depth45.2 mm
Width111.2 mm
Height66.4 mm
Weight298 g
Weight (including battery)340 g
