209
Using Menu Functions
Menu list
[Protect]
Set protection to disable picture deletion. Prevents deletion of important pictures.
[Playback] → [Protect]
1
Select picture (→206)
To clear all
Select [Protect] → [Cancel] → [Yes], and then press [MENU/SET]
When you set the write-protect switch on the card to the “LOCK” position, the picture is not
erased.
The picture is erased when formatting, even if it is protected.
May not be effective when using other devices.
[Rating]
You can label the pictures in five levels (ratings). When you have performed [Rating], the
following operations will be available.
Deletes all pictures except the labelled pictures.
You can check the rating level of the pictures by displaying the details of the file on
Windows 8, Windows 8.1, and Windows 10 (only JPEG pictures).
[Playback] → [Rating]
1
Select picture (→206)
2
Use to set the Rating levels (1 to 5) and press [MENU/SET]
(Repeat steps
1
and
2
to perform the setting with [Multi].)
To clear all
Select [Rating] → [Cancel] → [Yes], and then press [MENU/SET]
When you have performed [Rating] for group pictures, the setting applies to all pictures in the
group, and the number rating set is shown on the rating settings icon of the first picture. If the total
number of pictures is 1,000 or higher, [999+] is displayed.
Only when [Playback Mode] is set to [Normal Play], you can select [Cancel].
You can set only Rating [5] for AVCHD motion pictures.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DC-TZ200D and is the answer not in the manual?

Panasonic Lumix DC-TZ200D Specifications

General IconGeneral
Megapixel20.1 MP
Camera typeCompact camera
Sensor typeMOS
Image stabilizerYes
Total megapixels20.9 MP
Image sensor size1 \
Image formats supportedJPEG, RAW
Maximum image resolution5472 x 3648 pixels
Still image resolution(s)4864x3648, 3456x2592, 2432x1824, 5472x3648, 3888x2592, 2736x1824, 5472x3080, 3840x2160, 1920x1080, 3648x3648, 2592x2592, 1824x1824
Product colorBlack
Digital zoom4 x
Optical zoom15 x
Focal length range8.8 - 132 mm
Maximum aperture number6.4
Minimum aperture number3.3
Lens structure (elements/groups)13/11
Focus-
Normal focusing range (tele)1 m
Normal focusing range (wide)0.5 m
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/16000 s
Slowest camera shutter speed60 s
Viewfinder screen size0.21 \
Scene modesFood, Handheld night scene, Monochrome, Portrait, Sunset
White balanceArea white balance, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playbackHighlights, Movie, Single image, Slide show, Thumbnails
Self-timer delay2, 10 s
Image quality adjustmentContrast, Saturation, Sharpness
On Screen Display (OSD) languagesDEU, ENG, ESP, FRE, ITA, JPN
Video formats supportedAVCHD, MP4
Maximum video resolution3840 x 2160 pixels
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity80, 100, 125, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)25600
ISO sensitivity (min)80
Light exposure correction± 5EV (1/3EV step)
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.2
Field of view100 %
Display diagonal3 \
Display resolution1840 dot
Display diagonal (metric)7.5 cm
Flash modesAuto, Forced off, Forced on, Slow synchronization
Flash range (tele)1 - 3.9 m
Flash range (wide)0.6 - 6.8 m
Compatible memory cardsSD, SDHC, SDXC
USB version2.0
USB connectorMicro-USB B
HDMI connector typeMicro
Battery voltage7.2 V
Battery capacity1025 mAh
Quantity per pack1 pc(s)
Cables includedUSB
Weight and Dimensions IconWeight and Dimensions
Depth45.2 mm
Width111.2 mm
Height66.4 mm
Weight298 g
Weight (including battery)340 g
