Panasonic Lumix DC-TZ200D User Manual

25
Preparations
Inserting and removing the card (optional)
• Make sure that the camera is turned off.
1
Slide the release lever to the
[OPEN] position and open the
card/battery door
Release lever
2
Insert the card all the way
Do not touch the terminal
• Check the orientation of a card.
• Insert the card all the way firmly until
it clicks.
3
Close the card/battery door
and slide the release lever to
the [LOCK] position
[OPEN] [LOCK]
■
To remove card
Press the centre of the card.
Press Pull out
●
Keep the memory card out of reach of children to prevent swallowing.
●
To remove the card, turn the camera off and wait until the LUMIX indicator on the screen goes
off. (Failure to wait may cause the camera to malfunction and may damage the card or recorded
data.)

Panasonic Lumix DC-TZ200D Specifications

General

Megapixel	20.1 MP
Camera type	Compact camera
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	20.9 MP
Image sensor size	1 \
Image formats supported	JPEG, RAW
Maximum image resolution	5472 x 3648 pixels
Still image resolution(s)	4864x3648, 3456x2592, 2432x1824, 5472x3648, 3888x2592, 2736x1824, 5472x3080, 3840x2160, 1920x1080, 3648x3648, 2592x2592, 1824x1824
Product color	Black
Digital zoom	4 x
Optical zoom	15 x
Focal length range	8.8 - 132 mm
Maximum aperture number	6.4
Minimum aperture number	3.3
Lens structure (elements/groups)	13/11
Focus	-
Normal focusing range (tele)	1 m
Normal focusing range (wide)	0.5 m
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Viewfinder screen size	0.21 \
Scene modes	Food, Handheld night scene, Monochrome, Portrait, Sunset
White balance	Area white balance, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playback	Highlights, Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Image quality adjustment	Contrast, Saturation, Sharpness
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Video formats supported	AVCHD, MP4
Maximum video resolution	3840 x 2160 pixels
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	80, 100, 125, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	80
Light exposure correction	± 5EV (1/3EV step)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Field of view	100 %
Display diagonal	3 \
Display resolution	1840 dot
Display diagonal (metric)	7.5 cm
Flash modes	Auto, Forced off, Forced on, Slow synchronization
Flash range (tele)	1 - 3.9 m
Flash range (wide)	0.6 - 6.8 m
Compatible memory cards	SD, SDHC, SDXC
USB version	2.0
USB connector	Micro-USB B
HDMI connector type	Micro
Battery voltage	7.2 V
Battery capacity	1025 mAh
Quantity per pack	1 pc(s)
Cables included	USB

Weight and Dimensions

Depth	45.2 mm
Width	111.2 mm
Height	66.4 mm
Weight	298 g
Weight (including battery)	340 g
