Panasonic Lumix DC-TZ200D User Manual

32
Basics
Buttons/Ring/Dials/Levers Used for Recording
[LVF] button (Recording pictures using the viewfinder)
1
Press [LVF] button
Eye Sensor
[LVF] button
You can switch between monitor display and Viewfinder display.
Automatic switching
between viewfinder and
monitor
*
Viewfinder display
*
Monitor display
*
When [Eye Sensor AF] in the [Custom] ([Focus / Release Shutter]) menu is set to [ON], the camera
adjusts the focus automatically as the eye sensor is activated. Even when [Eye Sensor AF] is set
and the camera automatically adjusts the focus, a beep will not sound.
■
Automatic switching between viewfinder and monitor
The eye sensor automatically switches the display to viewfinder when your eye or an
object moves close to the viewfinder. When the eye or object moves away from the
viewfinder, the camera returns to monitor display.
■
About dioptre adjustment
Rotate the dioptre adjustment dial to adjust until you are able
to clearly see the characters displayed in the viewfinder.
●
If [LVF Display Speed] is set to [ECO 30fps] when the viewfinder is used, the camera can be
operated for a longer period since battery drainage is reduced.
●
The eye sensor may react depending on the shape of your eyeglasses, the way you hold the
camera, or whether the eye sensor is exposed to strong light.
●
During motion picture playback or Slide Show, the eye sensor does not operate.

Panasonic Lumix DC-TZ200D Specifications

General

Megapixel	20.1 MP
Camera type	Compact camera
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	20.9 MP
Image sensor size	1 \
Image formats supported	JPEG, RAW
Maximum image resolution	5472 x 3648 pixels
Still image resolution(s)	4864x3648, 3456x2592, 2432x1824, 5472x3648, 3888x2592, 2736x1824, 5472x3080, 3840x2160, 1920x1080, 3648x3648, 2592x2592, 1824x1824
Product color	Black
Digital zoom	4 x
Optical zoom	15 x
Focal length range	8.8 - 132 mm
Maximum aperture number	6.4
Minimum aperture number	3.3
Lens structure (elements/groups)	13/11
Focus	-
Normal focusing range (tele)	1 m
Normal focusing range (wide)	0.5 m
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Viewfinder screen size	0.21 \
Scene modes	Food, Handheld night scene, Monochrome, Portrait, Sunset
White balance	Area white balance, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playback	Highlights, Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Image quality adjustment	Contrast, Saturation, Sharpness
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Video formats supported	AVCHD, MP4
Maximum video resolution	3840 x 2160 pixels
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	80, 100, 125, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	80
Light exposure correction	± 5EV (1/3EV step)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Field of view	100 %
Display diagonal	3 \
Display resolution	1840 dot
Display diagonal (metric)	7.5 cm
Flash modes	Auto, Forced off, Forced on, Slow synchronization
Flash range (tele)	1 - 3.9 m
Flash range (wide)	0.6 - 6.8 m
Compatible memory cards	SD, SDHC, SDXC
USB version	2.0
USB connector	Micro-USB B
HDMI connector type	Micro
Battery voltage	7.2 V
Battery capacity	1025 mAh
Quantity per pack	1 pc(s)
Cables included	USB

Weight and Dimensions

Depth	45.2 mm
Width	111.2 mm
Height	66.4 mm
Weight	298 g
Weight (including battery)	340 g
