Panasonic Lumix DC-TZ200D User Manual

227
Wi-Fi/Bluetooth
Connecting the camera to a smartphone
Connecting the camera to a smartphone compatible with
Bluetooth Low Energy
You can connect the camera to a smartphone via a Bluetooth connection.
Supported
smartphones
Android: Android 5.0 or higher equipped with Bluetooth 4.0 or higher
(excluding those that do not support Bluetooth low energy)
iOS: iOS 9.3 or higher (excluding the iPad 2)
■
First-time connection
You need to set up pairing (connection) for the first time only. When pairing is set up, a
Wi-Fi connection is made automatically.
(On the camera)
→ [Setup] → [Bluetooth] → [Bluetooth]
→ [SET] → [Pairing]
• The camera enters pairing standby mode and displays its
device name.
(On your smartphone)
Start “Image App”
• If a message is displayed indicating that the smartphone is searching for cameras, close the
message.
Select [Bluetooth]
Turn on the Bluetooth
Select the device name displayed on the camera’s screen from the [Camera enable to
be registered] list
• Bluetooth connection between the camera and the smartphone will be made.
(For Android devices) A Wi-Fi connection will be made by selecting [Connection].
If you are using an Android device, follow the steps up to here to complete the setup.
Proceed to the steps below only if you are using an iOS device (iPhone/iPod touch/iPad).
• If [Wi-Fi Password] (→260) is set to [OFF] on the camera, select [Wi-Fi Setup]. (At the time of
purchase, [Wi-Fi Password] is set to [OFF])
• If [Wi-Fi Password] is set to [ON] on the camera, you need to install the profile.
Install the profile
• If the smartphone is locked with a passcode, enter the passcode to unlock the smartphone.
Exit the browser

Panasonic Lumix DC-TZ200D Specifications

General

Megapixel	20.1 MP
Camera type	Compact camera
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	20.9 MP
Image sensor size	1 \
Image formats supported	JPEG, RAW
Maximum image resolution	5472 x 3648 pixels
Still image resolution(s)	4864x3648, 3456x2592, 2432x1824, 5472x3648, 3888x2592, 2736x1824, 5472x3080, 3840x2160, 1920x1080, 3648x3648, 2592x2592, 1824x1824
Product color	Black
Digital zoom	4 x
Optical zoom	15 x
Focal length range	8.8 - 132 mm
Maximum aperture number	6.4
Minimum aperture number	3.3
Lens structure (elements/groups)	13/11
Focus	-
Normal focusing range (tele)	1 m
Normal focusing range (wide)	0.5 m
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Viewfinder screen size	0.21 \
Scene modes	Food, Handheld night scene, Monochrome, Portrait, Sunset
White balance	Area white balance, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playback	Highlights, Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Image quality adjustment	Contrast, Saturation, Sharpness
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Video formats supported	AVCHD, MP4
Maximum video resolution	3840 x 2160 pixels
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	80, 100, 125, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	80
Light exposure correction	± 5EV (1/3EV step)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Field of view	100 %
Display diagonal	3 \
Display resolution	1840 dot
Display diagonal (metric)	7.5 cm
Flash modes	Auto, Forced off, Forced on, Slow synchronization
Flash range (tele)	1 - 3.9 m
Flash range (wide)	0.6 - 6.8 m
Compatible memory cards	SD, SDHC, SDXC
USB version	2.0
USB connector	Micro-USB B
HDMI connector type	Micro
Battery voltage	7.2 V
Battery capacity	1025 mAh
Quantity per pack	1 pc(s)
Cables included	USB

Weight and Dimensions

Depth	45.2 mm
Width	111.2 mm
Height	66.4 mm
Weight	298 g
Weight (including battery)	340 g
