Panasonic Lumix DC-TZ200D User Manual

34
Basics
Buttons/Ring/Dials/Levers Used for Recording
Shutter button (Taking pictures)
1
Press the shutter button halfway (press lightly) to
focus on the subject
Focus display
( When focus is aligned: illuminated
When focus is not aligned: flashing)
Aperture value
Shutter speed
• The aperture value and shutter speed are displayed. (If the
aperture value and shutter speed are shown in red and flashing,
you do not have the appropriate exposure, unless you are using
the flash.)
2
Press the shutter button fully (push the button all the
way), and take the picture
●
Pictures can be taken only when the image is correctly focused as long as the [Focus/
Release Priority] is set to [FOCUS].
●
When [Monitor Display Speed] or [LVF Display Speed] (or both) is set to [ECO 30fps],
Digital Zoom is not available.
●
Even during menu operation or picture playback, if you press the shutter button halfway, you can
instantly set the camera ready for recording.
■
Focus range
Focus range is displayed when operating the zoom
Focus range
• The focus range is displayed in red when it is not focused
after pressing the shutter button halfway.
The focus range may change gradually depending on the zoom position.

Panasonic Lumix DC-TZ200D Specifications

General

Megapixel	20.1 MP
Camera type	Compact camera
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	20.9 MP
Image sensor size	1 \
Image formats supported	JPEG, RAW
Maximum image resolution	5472 x 3648 pixels
Still image resolution(s)	4864x3648, 3456x2592, 2432x1824, 5472x3648, 3888x2592, 2736x1824, 5472x3080, 3840x2160, 1920x1080, 3648x3648, 2592x2592, 1824x1824
Product color	Black
Digital zoom	4 x
Optical zoom	15 x
Focal length range	8.8 - 132 mm
Maximum aperture number	6.4
Minimum aperture number	3.3
Lens structure (elements/groups)	13/11
Focus	-
Normal focusing range (tele)	1 m
Normal focusing range (wide)	0.5 m
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Viewfinder screen size	0.21 \
Scene modes	Food, Handheld night scene, Monochrome, Portrait, Sunset
White balance	Area white balance, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playback	Highlights, Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Image quality adjustment	Contrast, Saturation, Sharpness
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Video formats supported	AVCHD, MP4
Maximum video resolution	3840 x 2160 pixels
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	80, 100, 125, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	80
Light exposure correction	± 5EV (1/3EV step)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Field of view	100 %
Display diagonal	3 \
Display resolution	1840 dot
Display diagonal (metric)	7.5 cm
Flash modes	Auto, Forced off, Forced on, Slow synchronization
Flash range (tele)	1 - 3.9 m
Flash range (wide)	0.6 - 6.8 m
Compatible memory cards	SD, SDHC, SDXC
USB version	2.0
USB connector	Micro-USB B
HDMI connector type	Micro
Battery voltage	7.2 V
Battery capacity	1025 mAh
Quantity per pack	1 pc(s)
Cables included	USB

Weight and Dimensions

Depth	45.2 mm
Width	111.2 mm
Height	66.4 mm
Weight	298 g
Weight (including battery)	340 g
