Panasonic Lumix DC-TZ200D User Manual

98
Focus, Brightness (Exposure) and Colour tone Settings
Taking pictures with Manual Focus
Operation Touch operation Description
Drag Moves the enlarged area.
—
Pinch out /
Pinch in
Enlarges/reduces the screen in small steps.
— Enlarges/reduces the screen in large steps.
—
*
1
Switches the enlarged display. (windowed/full screen)
*
2
[DISP.] [Reset] Resets the area to be enlarged back to the centre.
*
1
Cannot be set when using Intelligent Auto Mode.
*
2
The image of a part of the screen can be enlarged or reduced approximately 3 to 6 times.
The image of the entire screen can be enlarged or reduced approximately 3 to 10 times.
4
Press the shutter button halfway
• The recording screen will be displayed.
• The same operation can be performed by pressing [MENU/SET].
●
When [Focus Switching for Vert / Hor] in the [Custom] ([Focus / Release Shutter]) menu is set, you
can set a position of the enlarged area of MF Assist for each direction of the camera.
Quickly adjusting the focus using Auto Focus
In Manual Focus, the focus can be set on the subject through Auto Focus.
1
Touch [ ]
• Auto Focus is activated at the centre of the frame.
• Auto Focus also works with the following operations.
– Pressing the [AF/AE LOCK] button to which [AF-ON] is
assigned (→99)
– Pressing the function button to which [AF-ON] is assigned
(→47)
– Dragging the monitor and releasing your finger at the position
you want to focus on
• This function cannot be used when [4K Live Cropping] is set.

Panasonic Lumix DC-TZ200D Specifications

General

Megapixel	20.1 MP
Camera type	Compact camera
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	20.9 MP
Image sensor size	1 \
Image formats supported	JPEG, RAW
Maximum image resolution	5472 x 3648 pixels
Still image resolution(s)	4864x3648, 3456x2592, 2432x1824, 5472x3648, 3888x2592, 2736x1824, 5472x3080, 3840x2160, 1920x1080, 3648x3648, 2592x2592, 1824x1824
Product color	Black
Digital zoom	4 x
Optical zoom	15 x
Focal length range	8.8 - 132 mm
Maximum aperture number	6.4
Minimum aperture number	3.3
Lens structure (elements/groups)	13/11
Focus	-
Normal focusing range (tele)	1 m
Normal focusing range (wide)	0.5 m
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Viewfinder screen size	0.21 \
Scene modes	Food, Handheld night scene, Monochrome, Portrait, Sunset
White balance	Area white balance, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playback	Highlights, Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Image quality adjustment	Contrast, Saturation, Sharpness
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Video formats supported	AVCHD, MP4
Maximum video resolution	3840 x 2160 pixels
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	80, 100, 125, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	80
Light exposure correction	± 5EV (1/3EV step)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Field of view	100 %
Display diagonal	3 \
Display resolution	1840 dot
Display diagonal (metric)	7.5 cm
Flash modes	Auto, Forced off, Forced on, Slow synchronization
Flash range (tele)	1 - 3.9 m
Flash range (wide)	0.6 - 6.8 m
Compatible memory cards	SD, SDHC, SDXC
USB version	2.0
USB connector	Micro-USB B
HDMI connector type	Micro
Battery voltage	7.2 V
Battery capacity	1025 mAh
Quantity per pack	1 pc(s)
Cables included	USB

Weight and Dimensions

Depth	45.2 mm
Width	111.2 mm
Height	66.4 mm
Weight	298 g
Weight (including battery)	340 g
