21
Preparations
Charging battery
Charging the battery
We recommend charging in a location where the ambient temperature is between 10 °C
and 30 °C (50 °F to 86 °F) (same for the battery temperature).
Insert the battery into the camera.
Make sure that the camera is turned off.
The battery can be charged from an outlet or through a PC.
USB connection cable (supplied)
AC adaptor (supplied)
To the electrical outlet
Computer
Getting ready: Turn on the computer.
When charging the camera, connect the USB connection cable (supplied) to the
[USB/CHARGE] socket.
[USB/CHARGE] socket
• This terminal is located at the bottom when the camera is in an
upright position.
• Always check the direction of the socket, and hold the plug straight
to insert or remove it. (If the cable is inserted in the wrong direction,
the socket could become deformed and cause faulty operation.)
Also, do not insert into the wrong socket. Doing so may cause
damage to this unit.
To Next Page
