Panasonic LUMIX DMC-G7 User Manual

405
13. Others
The battery is a rechargeable lithium ion battery. Its ability to generate power comes
from the chemical reaction that takes place inside it. This reaction is susceptible to
the surrounding temperature and humidity. If the temperature is too high or too low,
the operating time of the battery will become shorter.
Always remove the battery after use.
•
Place the removed battery in a plastic bag, and store or keep away from metallic objects (clips,
etc.).
If you drop the battery accidentally, check to see if the body of the battery and the
terminals are damaged.
•
Inserting a damaged battery in the camera will damage the camera.
Bring charged spare batteries when going out.
•
Be aware that the operating time of the battery becomes shorter in low temperature conditions
such as at a ski resort.
• When you travel, do not forget to bring the battery charger (supplied) so that you can charge
the battery in the country that you are traveling in.
Dispose of unusable battery.
•
The battery has a limited life.
• Do not throw the battery into fire because it may cause an explosion.
• The unusable battery should be discarded in accordance with battery recycling laws. Call the
RBRC hotline at 1-800-822-8837 for information.
Do not allow battery terminals to come into contact with metal objects (such as
necklaces, hairpins, etc.).
•
This can cause short-circuiting or heat generation and you may be badly burned if you touch a
battery.
• The [CHARGE] indicator may blink under the influence of static electricity or electromagnetic
wave. This phenomenon has no effects on charging.
• If you use the battery charger near a radio, the radio reception may be disturbed.
Keep the charger 1 m (3.3 feet) or more away from radio.
• The charger may generate whirring sounds when it is being used. This is not a malfunction.
• After use, be sure to disconnect the power supply device from the electrical outlet.
(A very small amount of current is consumed if it is left connected.)
• Keep the terminals of the charger and battery clean.
Battery
Charger

Panasonic LUMIX DMC-G7 Specifications

General

Megapixel	16.00 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	16.84 MP
Image sensor size	- \
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4592 x 3448 pixels
Image sensor size (W x H)	17.3 x 13 mm
Still image resolution(s)	4592 x 3448, 3232 x 2424, 2272 x 1704, 1824 x 1368, 4592 x 3064, 3232 x 2160, 2272 x 1520, 1824 x 1216, 4592 x 2584, 3840 x 2160, 1920 x 1080, 1824 x 1024, 3424 x 3424, 2416 x 2416, 1712 x 1712, 1712 x 1712
Filter size	52 mm
Optical zoom	- x
Focal length range	14 - 42 mm
Maximum aperture number	22
Minimum aperture number	3.5
Number of diaphragm blades	7
Number of aspheric elements	1
Lens structure (elements/groups)	12/9
Maximum focal length (35mm film equiv)	84 mm
Minimum focal length (35mm film equiv)	28 mm
Auto focusing (AF) modes	Continuous Auto Focus, Flexible Spot Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/25 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	1/160 s
Flash range (wide)	- m
Flash exposure correction	±3EV (1/2; 1/3 EV step)
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum video resolution	3840 x 2160 pixels
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Vari-angle LCD display	-
Display resolution (numeric)	1040000 pixels
Viewfinder type	Electronic
USB version	2.0
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Children, Night landscape, Night portrait, Panorama, Pet, Portrait, Sports, Sunset
Photo effects	Negative film, Vivid
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
GPS (satellite)	No
Self-timer delay	2, 10 s
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	1200 mAh
Battery life (CIPA standard)	360 shots
Product color	Black
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	77.4 mm
Width	124.9 mm
Height	86.2 mm
Weight	360 g
Weight (including battery)	410 g
