Preparations
Inserting and removing the card (optional)/
the battery
- 18 - VQT4J31
• Set the camera ON/OFF switch to [OFF].
Do not touch the
terminal
Charged battery (check orientation)
Card
(check orientation: terminals face LCD)
Lever
Slide the release lever to the
[OPEN] position and open
the card/battery door
Release lever
[OPEN] [LOCK]
Insert the battery and card,
making sure that their
orientation is correct
• Battery: Insert the battery all the
way firmly until a locking
sound is heard, and check
that the lever is hooked
over the battery.
• Card: Insert the card all the way
firmly until it clicks.
Close the door and slide the
release lever to the [LOCK]
position
To Next Page
