S2. Voltage Chart
S2.1. Power Top P.C.B.
Note) Indicated voltage values are the standard values for the unit measured by the DC electronic circuit tester (high-impedance) with the chassis taken as standard.
Therefore, there may exist some errors in the voltage values, depending on the internal impedance of the DC circuit tester.
REF No. PIN No. REC
IC1004 1 2.8
IC1004 2 0
IC1004 3 1.2
IC1004 4 8.4
IC1004 5 0
IC1004 6 9.4
IC1005 1 3.3
IC1005 2 0
IC1005 3 1.2
IC1005 4 3
IC1005 5 0
IC1005 6 3.3
IC5001 1 1.4
IC5001 2 0.1
IC5001 3 1
IC5001 4 0.7
IC5001 5 1
IC5001 6 0
IC5001 7 2.8
IC5001 8 2.6
IC5001 9 2.6
IC5001 10 2.8
IC5001 11 2.8
IC5001 12 1.2
IC5001 13 1.2
IC5001 14 1.2
IC5001 15 0
IC5001 16 1.2
IC5001 17 1.2
IC5001 18 1.2
IC5001 19 0
IC5001 20 0.2
IC5001 21 0.2
IC5001 22 1.2
IC5001 23 1.2
IC5001 24 0
IC5001 25 1.4
IC5001 26 3
IC5001 27 0
IC5001 28 1.6
IC8001 1 4.9
IC8001 2 0
IC8001 3 0
IC8001 4 0
IC8001 5 4.9
IC9901 1 0
IC9901 2 2.7
IC9901 3 0
IC9901 4 0
IC9901 5 0
IC9901 6 0
IC9901 7 0
IC9901 8 0
Q1001 S 0
Q1001 D 0
Q1001 G 4.1
Q1003 1 3.6
Q1003 2 3.6
Q1003 3 1.7
REF No. PIN No. REC
Q1003 4 3.6
Q1003 5 3.6
Q1003 6 3.5
Q1005 S 0
Q1005 D 2.8
Q1005 G 0
Q1006 S 0
Q1006 D 1.8
Q1006 G 0
Q1050 1 3.6
Q1050 2 3.6
Q1050 3 0
Q1050 4 0
Q1050 5 0
Q1070 1 1.4
Q1070 2 0
Q1070 3 3.5
Q1070 4 9.4
Q1070 5 3.5
Q1072 S 0
Q1072 D 0.3
Q1072 G 0
Q8009 1 3.6
Q8009 2 3.6
Q8009 3 0
Q8009 4 0
Q8009 5 3.6
Q8009 6 3.6
QR1001 E 0
QR1001 C 0
QR1001 B 3.6
QR1002 E 0
QR1002 C 0.9
QR1002 B 0
QR1006 E 0
QR1006 C 0
QR1006 B 3.6
QR5001 E 0
QR5001 C 2.7
QR5001 B 0
QR9901 E 2.8
QR9901 C 2.7
QR9901 B 1
