S4. Schematic Diagram
S4.1. Interconnection Diagram
DMC-TZ1 INTERCONNECTION DIAGRAM
MAIN P.C.B.
(COMPONENT SIDE)
: (FOIL SIDE)
FP9001
33
32
31
29
28
27
26
30
POWER CTL SW
D1R8V
BL CHANGE1
LCD 8R5V
LCD8R5 OFF L
CCD POWER
ACADP IN
NC
25
23
24
21
20
22
NC
BAT THERMO
VIDEO MUTE
BACKUP BATT
AUDIO SCK
AUDIO SDATA
19
18
AUDIO CS
AUDIO PWM
17 DGND
16 DGND
15 DGND
14 DGND
13 VIDEO
12 VIDEO GND
11 SAND A3R1V
10 AUDIO AD IN
9 ST CH LV
8 SELF LED K
7 STROBE TRG
6 CABLE DET
5 STB PWM
4 USB CABLE IN
3 USB( - )
2 USB(+)
1 NC
34 BL MINUS
36 CCD MINUS
38 POWER ON L
40 SHUT HALF
42 SHUT FULL
44 AF3R4V
46 MODE DIAL
48 KEY IN2
50
D2R9V
35 BL PLUS
37 CCD12V
39 UNREG
41 MAIN A3R1V
43 AF3R4V
45 AF3R4V
47 D1R2V
49 D2R9V
51 5R0V
FP9901
20
21
22 24
25
26
27 23
POWER CTL SW
D1R8V
BL CHANGE1
LCD 8R5V
LCD8R5 OFF L
CCD POWER
ACADP IN
NC
28 30
29
32
33 31
NC
BAT THERMO
VIDEO MUTE
BACKUP BATT
AUDIO SCK
AUDIO SDATA
34
35
AUDIO CS
AUDIO PWM
36 DGND
37 DGND
38 DGND
39 DGND
40 VIDEO
41 VIDEO GND
42 SAND A3R1V
43 AUDIO AD IN
44 ST CH LV
45 SELF LED K
46 STROBE TRG
47 CABLE DET
48 STB PWM
49 USB CABLE IN
50 USB(
-
)
51 USB(+)
2 5R0V
19 BL MINUS 17 CCD MINUS 15 POWER SW ON 13 SHUT HALF
11 SHUT FULL
9 AF3R4V 7 MODE DIAL 5 KEY IN2 3 D2R9V
18 BL PLUS 16 CCD12V 14 UNREG 12 MAIN A3R1V 10
AF3R4V
8 AF3R4V 6 D1R2V 4 D2R9V
1 NC
1
2
4 5
6
7 8
9
10
11
13 14
15
16
3
12
LCD G
CSHV
CKV
COM
VVSS
VPRE
PCG
OEVE
STV
OEV
PVREF
LCD B
LCD R
VSS
STH
CKH2
FP9003
17
18
19
CKH1
PVDD
COM
3
2
1 4
DGND
BL RANK
BL MINUS
BL PLUS
FP9002
LCD UNIT
FP9004
1
2
3
5
6
7
8
4
MR VCC
NC
MRB
DGND
MRA
FM P
FM N
XVH+
9
11
10
13
14
12
XV
O-
YVH-
XVH-
Y DR+
Y DR-
XVO+
15
16
X DR-
X DR+
17 YVH+
18 YVO-
19 YVO+
20 SHUT2
21 SHU2
22 SHUT1
23 SHUT1
24 IRIS1
25 IRIS1
26 IRIS2
27 IRIS2
28 TME1 LED K
29 TME1
30
TME1 TME2 VCC
31 TME2LED K
32 TME2
33 DCM+
34 DCM+
35 DCM-
36 DCM-
37 CHP LED K
38 CHP VCC
39 CHP
CCD MINUS20
DGND19
DGND18
SDCD17
SDCMD16
SDDAT315
SDDAT214
13
12
11
10
9
8 7
6
5
4
3
36
35
34
33
32
31 30
29
28 27
26
25
24
23
22 21 CCD12V
CCD POWER
SDCLK
NC
NC
NC
NC
SDWP
SDDAT1
SDDAT0
CCD0
CCD2 CCD4
CCD3
CCD1
D2R9V D2R9V
CCD11
CCD10
CCD9
CCD8
CCD7 CCD6
CCD5
AF3R4V
AFE SCK
CCDHD
PS9001
FCK
CCD THERMO
CCDVD
2
1
37
38
39 40STROBE TRG
AFE SDATA
AFE CS
SD / AFE P.C.B.
(FOIL SIDE)
PP6501
40 AFE CS 39 AFE SDATA 38 AFE SCK 37 D2R9V 36 D2R9V 35 CCD1 34 CCD3 33 CCD4
32 CCD2
31 CCD0 30 SDDAT0 29 SDDAT1
28 SDWP
27 NC
26 NC
25 NC
24 NC
23 SDCLK
22 CCD POWER 21 CCD12V 20 CCD MINUS
19 DGND
18 DGND 17 SDCD 16 SDCMD 15 SDDAT3 14 SDDAT2 13 CCD11 12 CCD10
11
CCD9
10
CCD8
9
CCD7
8
CCD6
7
CCD5
6 AF3R4V 5 FCK 4 CCD THERMO 3 CCDVD 2 CCDHD 1 STROBE TRG
FP6501
33
32
31
29
28
27
26
30
CCD GND
CCD POWER
CCD THERMO
CCD GND
CCDOUT
VH
VL
V5L
25
23
24
21
20
22
V5R
CCD GND
CCD GND
H2
H1
HL
19
18
R
CCD GND
17 CCD GND
16 CCD GND
15 CCD GND
14 SUB
13 BSUB
12 V4
11 V5A
10 V5B
9 V6
8 V1S
7 V1
6 V2
5 V3R
4 V3L
3 V3A
2 V3B
1 CCD POWER SE
CCD
UNIT
LENS
UNIT
PS9901
1 USB(+) 2 USB(
-
)
3 USB GND
4 VIDEO OUT 5 USB CABLE IN
6 CABLE DET
7 LINE OUT 8 UNREG+
9 UNREG+
10 UNREG+
11
UNREG GND
12
UNREG GND
13
UNREG GND
14
UNREG GND
15 UNREG GND
16 SELF LED K 17 SELF LED A
18 VIDEO GND
19 NC 20 NC
PP2001
20 NC
19 NC
18 VIDEO GND
17 SELF LED A
16 SELF LED K
15 UNREG GND
14 UNREG GND
13 UNREG GND
12 UNREG GND
11 UNREG GND 10
UNREG+
9
UNREG+
8
UNREG+
7
LINE OUT
6 CABLE DET
5 USBCABLEIN
4 VIDEO OUT
3 USB GND
2 USB( - )
1 USB(+)
JACK P.C.B.
(COMPONENT SIDE)
JK9901
BATTERY
POWER / TOP P.C.B.
(FOIL SIDE)
3BAT -
2BAT THERMO
1BAT+
