- 9 -
Before Use
15 Strap eyelet (P24)
•
To prevent dropping, be sure to attach the
supplied strap and fit it to your wrist.
16 Lens barrel
17 [HDMI] socket (P155)
•
Do not connect with any cable other than an
HDMI micro cable. Doing so may cause
malfunction.
18 [AV OUT/DIGITAL] socket (P13, 156, 158,
160)
•
This socket is also used when charging the battery.
19 Microphone
•
Be careful not to cover the microphone with
your finger.
20 Camera [ON/OFF] button (P22)
21 Zoom lever (P59)
22 [Wi-Fi] button (P126, 129)
23 Shutter button (P26, 31)
24 Mode dial (P25)
25 Tripod mount
•
It is not possible to attach and fasten a tripod
with a screw length of 5.5 mm (0.22 inch) or
more securely to the camera. Doing so may
damage the camera.
• It may not be possible to attach certain types
of tripods properly.
26 Card/Battery door (P12, 18)
27 Release lever (P12, 18)
To Next Page
