No. SX-DSV03335 - 98-
R2.0 Industrial Device Solution Business Unit, Panasonic Corporation
Model No.
MFDLTA4BM
MFDLTB4BM
Power supply input
3 phase 400 V
3 phase 400 V
Maximum output current
40 A
60 A
Regenerative resistor
Built-in
Built-in
Auto gain tuning function
Provided
Provided
Dynamic brake function
Provided
Provided
Operation temperature
0-55 ℃
0-55 ℃
Control power cable
HVSF 0.52 mm
2
HVSF 0.52 mm
2
AWG20
AWG20
Main power supply cable
HVSF 3.5 mm
2
HVSF 3.5 mm
2
AWG12
AWG12
Ground cable
HVSF 3.5 mm
2
HVSF 3.5 mm
2
AWG12
AWG12
Motor cable
HVSF 3.5 mm
2
HVSF 3.5 mm
2
AWG12
AWG12
Inrush current
(Main power supply) (*1)
Max．30 A
Max．30 A
Inrush current
(Control power supply) (*1)
Max．48 A
Max．48 A
Weight
Approx.5.2 kg
Approx5.2 kg
Dimensions
Size F
Size F
(*1) The current is the value calculated with the voltage as 400 V when the product power input voltage is
400 V(Control circuit power is 24 VDC) specification .
