Panasonic MCDLT35BM - Parameter Reference Guide

No.SX-DSV03335
Cate
Pr.
Parameter
Defaul
t
value
Cate
Pr.
Parameter
Defaul
t
value
Cate
Pr.
Parameter
Defaul
t
value
Cate
Pr.
Parameter
Defaul
t
value
Cate
Pr.
Parameter
Defaul
t
value
0 0 For Manufacturer use 1
1 For Manufacturer use 0
2
Real-time auto-gain tuning setup
1
3
Selection of machine stiffness at real-
time auto-gain tuning
Size A-C 13
Size D-H 11
4 Inertia ratio 250
5 No use -
6 No use -
7 No use -
8 For Manufacturer use 0
9 For Manufacturer use 1
10 For Manufacturer use 1
11
Numerator of pulse output
division
2500
12
Reversal of pulse output logic/
out
p
ut source selection
0
13 1st torque limit 500
14
Position deviation excess setup
100000
15 For Manufacturer use 1
16
External regenerative resistor
setu
p
Size A,B,G,H 3
Size C-F 0
17
Load factor of external
re
g
enerative resistor selection
0
18 For Manufacturer use 0
PARAMETER MODEL
*1 When checking directly value of parameter-file with a text data etc., it does not show the decimal point. Ex) Pr6.24 Load change compensation filter ･･･ Value of Panaterm ： 0.53 / Value of parameter-file ： 53
* Parameter names in the table correspond to the DD motor (rotary type). For parameter names and setting values corresponding to linear motors, refer to the technical document.
MINAS-A6B(BL/BM) series
1/11
