Panasonic MCDLT35BM - Page 106

No.SX-DSV03335
Cate
Pr.
Parameter
Defaul
t
value
Cate
Pr.
Parameter
Defaul
t
value
Cate
Pr.
Parameter
Defaul
t
value
Cate
Pr.
Parameter
Defaul
t
value
Cate
Pr.
Parameter
Defaul
t
value
5
0 No use
- 5
31 USB axis address
15
62 No use
-
1 No use
-
32 No use
-
63 No use
-
2 No use
-
33
Pulse regenerative output
limitsetu
p
0
64 No use
-
3
Denominator of pulse
out
p
utdivision
0
34 For Manufacturer use
4
65 No use
-
4 Over-travel inhibit input setup
1
35 No use
-
66
*
1
Deterioration diagnosis
conver
g
ence
j
ud
g
ment time
0
5 Sequence at over-travel inhibit
0
36 For Manufacturer use
0
67
Deterioration diagnosis inertia ratio
u
pp
er limit
0
6 Sequence at Servo-off
0
37 No use
-
68
Deterioration diagnosis inertia ratio
lower limit
0
7 Sequence at main power off
0
38 No use
-
69
*
1
Deterioration diagnosis unbalanced load
upper limit
0
8
LV trip selection at main power
of
f
0
39 No use
-
70
*
1
Deterioration diagnosis unbalanced load
lower limit
0
9
Detection time of main power off
2000
40 No use
-
71
*
1
Deterioration diagnosis dynamic friction
upper limit
0
10 Sequence at alarm
0
41 No use
-
72
*
1
Deterioration diagnosis dynamic friction
lower limit
0
11
Torque setup for emergency stop
0
42 No use
-
73
*
1
Deterioration diagnosis viscous friction
upper limit
0
12 Over-load level setup
0
43 No use
-
74
*
1
Deterioration diagnosis viscous friction
lower limit
0
13 Over-speed level setup
0
44 No use
-
75
Deterioration diagnosis velocity
settin
g
0
14
*
1
Motor working range setup
1.0
45
Quadrant glitch positive-direction
com
p
ensation value
0
76
Deterioration diagnosis torque
avera
g
e time
0
15
Control input signal reading setup
0
46
Quadrant glitch negative-direction
com
p
ensation value
0
77
*
1
Deterioration diagnosis torque
u
pp
er limit
0
16
Alarm clear input(A-CLR)
setu
p
1
47
Quadrant glitch compensation
dela
y
time
0
78
*
1
Deterioration diagnosis torque
lower limit
0
17 No use
-
48
Quadrant glitch compensation
filter settin
g
L
0
18 No use
-
49
Quadrant glitch compensation
filter settin
g
H
0
19 No use
-
50 For Manufacturer use
0
20 Position setup unit select
0
51 For Manufacturer use
0
21 Selection of torque limit
1
52 For Manufacturer use
0
22
*
2
2nd torque limit
500
53 For Manufacturer use
0
23 No use
-
54 For Manufacturer use
0
24 No use
-
55 For Manufacturer use
0
25
*
2
For Manufacturer use
0
56
Slow stop deceleration time
settin
g
0
26
*
2
For Manufacturer use
0
57
Slow stop S-shape acceleration
and deceleration settin
g
0
27 No use
-
58 No use
-
28 No use
-
59 No use
-
29 For Manufacturer use
2
60 No use
-
30 No use
-
61 No use
-
6/11
PARAMETER MODEL MINAS-A6B(BL/BM) series
*1 When checking directly value of parameter-file with a text data etc., it does not show the decimal point. Ex) Pr6.24 Load change compensation filter ･･･ Value of Panaterm ： 0.53 / Value of parameter-file ： 53
* Parameter names in the table correspond to the DD motor (rotary type). For parameter names and setting values corresponding to linear motors, refer to the technical document.
