12 Shape object
• Under “Position, rotation”, enter a value for “Rotation angle [°]” to rotate all shapes of a
shape object. Enter a positive value for counterclockwise rotation and a negative value for
clockwise rotation.
Alternatively, rotate the shape object in the marking image editor with the circular arrow
symbol . Select the object in the marking image editor. Position the pointer over the
symbol. Click and drag in a circular motion.
The rotation center is the center of the marking field.
Related topics
Add or delete shapes in an existing shape object (page 139)
140 ME-NAVIS2-OP-1
