15 2D code object
Square symbols
Character type
Symbol size
Numeric Alphanumeric Kanji
Error correction
overhead [%]
10x10 6 3 – 62.5
12x12 10 6 1 58.3
14x14 16 10 3 55.6
16x16 24 16 5 50
18x18 36 25 8 43.8
20x20 44 31 10 45
22x22 60 43 14 40
24x24 72 52 17 40
26x26 88 64 21 38.9
32x32 124 91 30 36.7
36x36 172 127 42 32.8
40x40 228 169 56 29.6
44x44 288 214 71 28
48x48 259 86 28.1
52x52 101 29.2
64x64 138 28.6
72x72 182 28.1
80x80 226 29.6
88x88
299
299
286 28
Rectangular symbols
Character type
Symbol size
Numeric Alphanumeric Kanji
Error correction
overhead [%]
8x18 10 6 1 58.3
8x32 20 13 4 52.4
12x26 32 22 7 46.7
12x36 44 31 10 45
16x36 64 46 15 42.9
16x48 98 72 23 36.4
