Panasonic PT-CW230E

Technical Information
74
- ENGLISH
Appendix
Mode
Display
resolution *
1
(dots)
Scanning
frequency
Dot clock
frequency
(MHz)
quality *
2
PnP*
3
3D
Display
Format
H (kHz)
V
(Hz)
PT-
CW230E
PT-
CX200E
D-VGA 640 x 480 31.469 59.940 25.175 A A ○ ○
H
D-SVGA 800 x 600
37.879 60.320 40.000 A A ○ ○
76.302 119.972 73.250 A A ○
D-XGA 1 024 x 768
43.363 60.000 65.000 A AA ○ ○
97.551 119.989 115.500 A AA ○
D-SXGA 1 280 x 1 024
63.980 60.020 108.000 A A ○
60.276 58.069 93.067 A A
D-SXGA+ 1 400 x 1 050
65.350 60.120 122.850 A A
65.120 59.900 122.430 A A
62.500 58.600 108.000 A A ○
64.744 59.948 101.000 A A ○
65.317 59.978 121.750 A A ○
D-WXGA
1 360 x 768 97.533 119.967 148.250 A A ○
1 376 x 768 48.360 60.00 86.670 A A ○
1 280 x 768
47.776 59.870 79.500 AA A ○
60.289 74.893 102.250 AA A
68.633 84.837 117.500 AA A
97.396 119.798 140.250 AA A ○
1 280 x 800
49.600 60.050 79.360 AA A ○
41.200 50.000 68.557 AA A ○
49.702 59.810 83.500 AA A ○
101.563 119.909 146.250 AA A ○
D-WXGA+ 1 440 x 900 55.935 59.887 106.500 A A ○
D-WSXGA+ 1 680 x 1 050 65.290 59.954 146.250 A A
“i” added to the resolution value indicates an interlaced signal.*1 :
Picture quality is indicated by the following symbols.*2 :
AA: Maximum picture quality can be obtained.
A: Signals are converted by the image processing circuit.
The signal marked with circles (O) can be applied by plug-and-play device.*3 :
Note
The number of display dots is 1 280 x 800 for the PT-CW230E and 1 024 x 768 for the PT-CX200E.
z
A signal with a different resolution will be projected after converting the resolution to match the projector
display.
When interlaced signals are connected, icker may occur on the projected image.
z
