Panasonic PT-CW230E - Projector Specifications; General and Display Specifications; Signal and Projection Specifications

ENGLISH -
75
Appendix
Specications
Model No. PT-CW230E PT-CX200E
Power supply
AC100 V - 240 V 50 Hz/60 Hz
Power consumption
100 V - 240 V 4.5 A-2.2 A, 350 W
When [Standby mode] of [Setting] is set to [ECO]: 0.45W
When [Standby mode] of [Setting] is set to [Network]: 11.0W
DLP chip
Size
0.65"(aspect ratio 16 : 10) 0.55"(aspect ratio 4 : 3)
Display System
One-unit DLP chip, DLP type
Number of pixels
1 024 000 pixels
(1 280 x 800 dots)
786 432 pixels
(1 024 x 768 dots)
Lens
Manual focus
F 2.5, f 4.83 mm
Luminous lamp
275 W UHM lamp
Light output *
1
2 500 lm 2 000 lm
Applicable
scanning
frequency
*
2
for RGB signal
Horizontal 15 kHz to 93 kHz, Vertical 50 Hz to 120 Hz
Dot clock frequency: 150 MHz or less
for YP
B
P
R
signal
[525i(480i)] Horizontal 15.75 kHz, Vertical 60 Hz
[525p(480p)] Horizontal 31.5 kHz, Vertical 60 Hz
[750(720)/60p] Horizontal 45 kHz, Vertical 60 Hz
[1 125(1 080)/60i] Horizontal 33.75 kHz, Vertical 60 Hz
[625i(576i)] Horizontal 15.63 kHz, Vertical 50 Hz
[625p(576p)] Horizontal 31.25 kHz, Vertical 50 Hz
[750(720)/50p] Horizontal 37.5 kHz, Vertical 50 Hz
[1 125(1 080)50i] Horizontal 28.13 kHz, Vertical 50 Hz
HD/SYNC and V terminals are not compliant with 3 value composite SYNC
z
for Video signal
(including S-video)
Horizontal 15.75 kHz / 15.63 kHz, Vertical 50 Hz / 60 Hz
for HDMI signal
525p(480p), 625 p(576p), 750(720)/60p, 750(720)/50p, 1 125(1 080)/60p, 1 125(1 080)/50p,
1 125(1 080)/60i, 1 125(1 080)/50i
Displayable resolution: VGA to WSXGA+ (non-interlace)
z
Dot clock frequency: up to 150 MHz
z
Color system
7 (NTSC, NTSC4.43, PAL, PAL-N, PAL-M, SECAM, PAL60)
Projection size
1.524 m -2.794 m (60"-110") 1.397 m -2.286 m (55"-90")
Screen aspect ratio
16 : 10 4 : 3
Projection scheme
Ceiling/oor, front/rear, vertical upwards/downwards
Speaker
1 (3.7 cm round-type)
Maximum usable volume output
10W
Contrast ratio *
1
2 000 : 1 (all white / all black)
Measurement, measuring conditions and method of notation all comply with ISO21118 international *1 :
standards.
For details of video signals that can be projected using this projector, refer to “List of compatible signals”. *2 :
(
Æ
pages 71-74)
