Basic Operation
Press ENTER.3.
A “Change registered signals” screen will appear.
•
RENAME
NAME
MEMORY NO
INPUT
fH
fV
SYNC.STATE
SXGA60-A1
A1
RGB1
64.00kHz
60.00Hz
H(POS)
V(POS)
ABCDEFGHIJKLMNO
PQRSTUVWXYZ;:,.
abcdefghijklmno
pqrstuvwxyz/+-*
0123456789 _@[]
< > BS OK CANCEL
Press ENTER.4.
Note
To rename a registered signal, perform steps 4 and •
5 on page 44.
Procedure to switch to sub
memory
Press ◄► on normal screen 1.
(when the menu is not
displayed).
The screen will show a list of the sub-memories •
registered for the currently entered signal.
Press ▲▼◄► to select the 2.
sub-memory signal to be
switched in the “SUB MEMORY
LIST”.
Press ENTER.3.
The sub-memory selected in step 2 will now •
become active.
How to erase sub memory
The currently selected SUB MEMORY is deleted
by pressing DEFAULT at the “REGISTERED
SIGNAL LIST”.
On-screen indications
1
Input switching / signal switching
This shows the registered signal name on the
status screen for signal switching.
INPUT
NAME
MEMORY NO
RGB1
RGB
A1(1-2)
2
Details of registered signal
REGISTERED SIGNAL STATUS
NAME
MEMORY NO
INPUT
fH
fV
SYNC.STATE
SXGA60-A1
A5 (1-2)
RGB1
63.98kHz
60.02Hz
H(POS)
V(POS)
The designation can be set by the sub memory •
items.
MEMORY NO : A1 (1-2)
Sub memory number
The place in which address code (A1,
A2, ..., H7 and H8) signals are registered
Note
Restrictions
The total number of registered signals (including •
any corresponding sub-memories) is 96.
