Basic Operation
Press ◄► to adjust the 3.
correction amount.
The value changes from -127 to 127.•
Press ▲▼ to select “SUB 4.
KEYSTONE” or “LINEARITY”.
Press ◄► to adjust the 5.
correction amount.
The value changes from -127 to 127.•
Note
Adjust the “SUB KEYSTONE” or “LINEARITY” after •
adjusting the “KEYSTONE”.
The variable range of the “SUB KEYSTONE” or
“LINEARITY” changes in response to the adjusted
value of the “KEYSTONE”.
“SUB KEYSTONE” is a function which is used to •
correct keystone distortion when the lens has been
shifted to the left or right. Keystone correction can
only be carried out for the area at the top-right of
the screen. However, this adjustment cannot be
used when “KEYSTONE” is set to “0”.
Pressing DEFAULT of the remote control will •
restore the factory default (“KEYSTONE”: 0, “SUB
KEYSTONE”: 0, “LINEARITY”: 0).
The adjusted value is reflected in other input •
signals.
Keystone distortion can be corrected to ±40° of •
the angle of tilt for the projector against the screen.
(The range for the angle of elevation is within ±22°
when using a lens with a fixed focal point, and it is
within ±28° when using an LE6 lens.)
If keystone correction is used, edge blending •
adjustment cannot be performed properly.
To Next Page
