Panasonic PT-MZ10K

Chapter 7 Appendix — Technical information
ENGLISH - 235
List of single link SDI compatible signals
The following table species the single link SDI signals that the projector can project.
Signal name
(SIGNAL FORMAT)
Resolution
(Dots)
Scanning freq.
Dot clock
freq.
(MHz)
Format Color format Sampling
Horizontal
(kHz)
Vertical
(Hz)
720/60p 1 280 x 720 45.0 60.0
*1
74.3 HD-SDI YP
B
P
R
4:2:2 10bit
720/50p 1 280 x 720 37.5 50.0 74.3 HD-SDI YP
B
P
R
4:2:2 10bit
1080/60i
1 920 x 1 080i 33.8 60.0
*1
74.3 HD-SDI YP
B
P
R
4:2:2 10bit
1 920 x 1 080i 33.8 60.0
*1
74.3 3G-SDI Level-A RGB 4:4:4 10bit
1 920 x 1 080i 33.8 60.0
*1
74.3 3G-SDI Level-B RGB 4:4:4 10bit
1 920 x 1 080i 33.8 60.0
*1
74.3 3G-SDI Level-A RGB 4:4:4 12bit
1 920 x 1 080i 33.8 60.0
*1
74.3 3G-SDI Level-B RGB 4:4:4 12bit
1080/50i
1 920 x 1 080i 28.1 50.0 74.3 HD-SDI YP
B
P
R
4:2:2 10bit
1 920 x 1 080i 28.1 50.0 74.3 3G-SDI Level-A RGB 4:4:4 10bit
1 920 x 1 080i 28.1 50.0 74.3 3G-SDI Level-B RGB 4:4:4 10bit
1 920 x 1 080i 28.1 50.0 74.3 3G-SDI Level-A RGB 4:4:4 12bit
1 920 x 1 080i 28.1 50.0 74.3 3G-SDI Level-B RGB 4:4:4 12bit
1080/24p
1 920 x 1 080 27.0 24.0
*1
74.3 HD-SDI YP
B
P
R
4:2:2 10bit
1 920 x 1 080 27.0 24.0
*1
74.3 3G-SDI Level-A RGB 4:4:4 10bit
1 920 x 1 080 27.0 24.0
*1
74.3 3G-SDI Level-B RGB 4:4:4 10bit
1 920 x 1 080 27.0 24.0
*1
74.3 3G-SDI Level-A RGB 4:4:4 12bit
1 920 x 1 080 27.0 24.0
*1
74.3 3G-SDI Level-B RGB 4:4:4 12bit
1080/24sF
1 920 x 1 080i 27.0 48.0
*1
74.3 HD-SDI YP
B
P
R
4:2:2 10bit
1 920 x 1 080i 27.0 48.0
*1
74.3 3G-SDI Level-A RGB 4:4:4 10bit
1 920 x 1 080i 27.0 48.0
*1
74.3 3G-SDI Level-B RGB 4:4:4 10bit
1 920 x 1 080i 27.0 48.0
*1
74.3 3G-SDI Level-A RGB 4:4:4 12bit
1 920 x 1 080i 27.0 48.0
*1
74.3 3G-SDI Level-B RGB 4:4:4 12bit
1080/25p
1 920 x 1 080 28.1 25.0 74.3 HD-SDI YP
B
P
R
4:2:2 10bit
1 920 x 1 080 28.1 25.0 74.3 3G-SDI Level-A RGB 4:4:4 10bit
1 920 x 1 080 28.1 25.0 74.3 3G-SDI Level-B RGB 4:4:4 10bit
1 920 x 1 080 28.1 25.0 74.3 3G-SDI Level-A RGB 4:4:4 12bit
1 920 x 1 080 28.1 25.0 74.3 3G-SDI Level-B RGB 4:4:4 12bit
1080/30p
1 920 x 1 080 33.8 30.0
*1
74.3 HD-SDI YP
B
P
R
4:2:2 10bit
1 920 x 1 080 33.8 30.0
*1
74.3 3G-SDI Level-A RGB 4:4:4 10bit
1 920 x 1 080 33.8 30.0
*1
74.3 3G-SDI Level-B RGB 4:4:4 10bit
1 920 x 1 080 33.8 30.0
*1
74.3 3G-SDI Level-A RGB 4:4:4 12bit
1 920 x 1 080 33.8 30.0
*1
74.3 3G-SDI Level-B RGB 4:4:4 12bit
1080/60p
1 920 x 1 080 67.5 60.0
*1
148.5 3G-SDI Level-A YP
B
P
R
4:2:2 10bit
1 920 x 1 080 67.5 60.0
*1
148.5 3G-SDI Level-B YP
B
P
R
4:2:2 10bit
1080/50p
1 920 x 1 080 56.3 50.0 148.5 3G-SDI Level-A YP
B
P
R
4:2:2 10bit
1 920 x 1 080 56.3 50.0 148.5 3G-SDI Level-B YP
B
P
R
4:2:2 10bit
2K/24p
2 048 x 1 080 27.0 24.0
*1
74.3 3G-SDI Level-A RGB 4:4:4 10bit
2 048 x 1 080 27.0 24.0
*1
74.3 3G-SDI Level-B RGB 4:4:4 10bit
2 048 x 1 080 27.0 24.0
*1
74.3 3G-SDI Level-A RGB 4:4:4 12bit
2 048 x 1 080 27.0 24.0
*1
74.3 3G-SDI Level-B RGB 4:4:4 12bit
2K/25p
2 048 x 1 080 28.1 25.0 74.3 3G-SDI Level-A RGB 4:4:4 10bit
2 048 x 1 080 28.1 25.0 74.3 3G-SDI Level-B RGB 4:4:4 10bit
2 048 x 1 080 28.1 25.0 74.3 3G-SDI Level-A RGB 4:4:4 12bit
2 048 x 1 080 28.1 25.0 74.3 3G-SDI Level-B RGB 4:4:4 12bit
2K/30p
2 048 x 1 080
33.8 30.0
*1
74.3 3G-SDI Level-A RGB 4:4:4 10bit
2 048 x 1 080 33.8 30.0
*1
74.3 3G-SDI Level-B RGB 4:4:4 10bit
2 048 x 1 080 33.8 30.0
*1
74.3 3G-SDI Level-A RGB 4:4:4 12bit
2 048 x 1 080 33.8 30.0
*1
74.3 3G-SDI Level-B RGB 4:4:4 12bit
2K/48p
2 048 x 1 080 54.0 48.0
*1
148.5 3G-SDI Level-A YP
B
P
R
4:2:2 10bit
2 048 x 1 080 54.0 48.0
*1
148.5 3G-SDI Level-B YP
B
P
R
4:2:2 10bit
2K/50p
2 048 x 1 080 56.3 50.0 148.5 3G-SDI Level-A YP
B
P
R
4:2:2 10bit
2 048 x 1 080 56.3 50.0 148.5 3G-SDI Level-B YP
B
P
R
4:2:2 10bit
