Panasonic PT-RZ690

Chapter 4 Settings — [NETWORK] menu
170 - ENGLISH
7) Press
asqw
to select a character, and press the <ENTER> button.
f
Enter the current password.
8) After entering the password, press
asqw
to select [OK], and press the <ENTER> button.
f
The
[ADMINISTRATOR ACCOUNT]
screen is displayed.
9) Press
as
to select [USER NAME] under [NEW], and press the <ENTER> button.
f
The
[USER NAME]
screen is displayed.
10) Press
asqw
to select a character, and press the <ENTER> button.
f
Enter a new user name.
f
Enter the current user name if you do not want to change it.
f
Up to 16 characters can be entered.
11) After entering the user name, press
asqw
to select [OK], and press the <ENTER> button.
f
The
[ADMINISTRATOR ACCOUNT]
screen is displayed.
12) Press
as
to select [PASSWORD] under [NEW], and press the <ENTER> button.
f
The
[PASSWORD]
screen is displayed.
13) Press
asqw
to select a character, and press the <ENTER> button.
f
Enter a new password.
f
Up to 16 characters can be entered.
f
Enter the current password if you do not want to change it.
14) After entering the password, press
asqw
to select [OK], and press the <ENTER> button.
f
The
[ADMINISTRATOR ACCOUNT]
screen is displayed.
15) Press
as
to select [PASSWORD CONFIRM] under [NEW], and press the <ENTER> button.
f
The
[PASSWORD CONFIRM]
screen is displayed.
16) Enter the password entered in Step 13).
17) After entering the password, press
asqw
to select [OK], and press the <ENTER> button.
f
The
[ADMINISTRATOR ACCOUNT]
screen is displayed.
18) Press
as
to select [STORE], and press the <ENTER> button.
f
The conrmation screen is displayed.
19) Press
qw
to select [OK], and press the <ENTER> button.
Note
f
For restrictions on character strings that can be set for password, refer to [PASSWORD POLICY] (
x
page 168) .
f
The user name and password of the administrator account can also be changed on the [Set up password] page (
x
page 192) of the web
control screen.
f
The user name and password of a standard user account without administrator rights can be set on the [Set up password] page (
x
page 192)
of the web control screen.
[NETWORK CONTROL]
Set the network control of this projector.
Setting the password of the administrator account (
x
page 168) is required for using the network function of the
projector.
1) Press
as
to select [NETWORK CONTROL].
2) Press the <ENTER> button.
f
The
[NETWORK CONTROL]
screen is displayed.
3) Press
as
to select an item, and press
qw
to change the setting.
[WEB CONTROL]
Set to [ON] to control with the web browser.
[COMMAND CONTROL]
Set to [ON] to control with the <SERIAL/MULTI PROJECTOR SYNC IN>/<SERIAL/MULTI
PROJECTOR SYNC OUT> terminal control command format (
x
page 222) . Refer to “Control
commands via LAN” (
x
page 216).
