Chapter 2 Getting Started — Setting up
ENGLISH - 45
r
When the screen aspect ratio is 4:3
(Unit: m)
Lens type Zoom Lens
Projection lens Model No.
Standard zoom
lens/ET-DLE170
ET-DLE020 ET-DLE060 ET-DLE085 ET-DLE105
Throw ratio
*1
2.06-2.90:1 0.337-0.361:1 0.724-0.965:1 0.943-1.18:1 1.18-1.59:1
Projected image size Projection distance (L)
Diagonal (SD)
Height
(SH)
Width
(SW)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
1.27 (50") 0.762 1.016 2.07 2.92 ― ― 0.71 0.96 0.94 1.18 1.18 1.60
1.52 (60") 0.914 1.219 2.50 3.52 ― ― 0.87 1.16 1.14 1.42 1.42 1.93
1.78 (70") 1.067 1.422 2.93 4.12 ― ― 1.02 1.37 1.33 1.67 1.67 2.26
2.03 (80") 1.219 1.626 3.35 4.72 ― ― 1.18 1.57 1.53 1.91 1.91 2.59
2.29 (90") 1.372 1.829 3.78 5.31 ― ― 1.33 1.77 1.73 2.16 2.16 2.92
2.54 (100") 1.524 2.032 4.21 5.91 0.67 0.72 1.48 1.97 1.93 2.40 2.41 3.25
3.05 (120") 1.829 2.438 5.07 7.11 0.81 0.87 1.79 2.38 2.32 2.89 2.90 3.91
3.81 (150") 2.286 3.048 6.35 8.91 1.03 1.10 2.25 2.99 2.91 3.62 3.63 4.89
5.08 (200") 3.048 4.064 8.50 11.90 1.38 1.47 3.02 4.00 3.90 4.84 4.86 6.54
6.35 (250") 3.810 5.080 10.64 14.89 1.73 1.85 3.79 5.01 4.89 6.07 6.09 8.19
7.62 (300") 4.572 6.096 12.78 17.88 2.08 2.23 4.56 6.03 5.88 7.29 7.32 9.84
8.89 (350") 5.334 7.112 14.93 20.88 2.43 2.60 5.33 7.04 6.86 8.51 8.55 11.48
10.16 (400") 6.096 8.128 17.07 23.87 2.78 2.98 6.10 8.05 7.85 9.73 9.78 13.13
12.70 (500") 7.620 10.160 21.36 29.85 ― ― 7.64 10.08 9.82 12.17 12.23 16.42
15.24 (600") 9.144 12.192 25.64 35.84 ― ― 9.18 12.11 11.80 14.62 14.69 19.72
*1 The throw ratio is based on the value during projection of 2.03 m (80") projected image size. When the Zoom Lens (Model No.: ET-DLE020) is
attached, the throw ratio is based on the value during projection of 3.81 m (150") projected image size.
(Unit: m)
Lens type Zoom Lens
Projection lens Model No. ET-DLE150 ET-DLE250 ET-DLE350 ET-DLE450
Throw ratio
*1
1.56-2.27:1 2.73-4.35:1 4.30-6.55:1 6.46-10.3:1
Projected image size Projection distance (L)
Diagonal (SD)
Height
(SH)
Width
(SW)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
1.27 (50") 0.762 1.016 1.56 2.29 2.75 4.39 4.32 6.60 6.45 10.37
1.52 (60") 0.914 1.219 1.89 2.75 3.31 5.28 5.21 7.95 7.80 12.50
1.78 (70") 1.067 1.422 2.21 3.22 3.88 6.17 6.10 9.29 9.14 14.63
2.03 (80") 1.219 1.626 2.54 3.69 4.44 7.07 7.00 10.64 10.49 16.77
2.29 (90") 1.372 1.829 2.86 4.15 5.01 7.96 7.89 11.99 11.84 18.90
2.54 (100") 1.524 2.032 3.18 4.62 5.57 8.85 8.78 13.34 13.19 21.03
3.05 (120") 1.829 2.438 3.83 5.55 6.71 10.64 10.56 16.03 15.89 25.30
3.81 (150") 2.286 3.048 4.80 6.96 8.40 13.32 13.24 20.07 19.94 31.70
5.08 (200") 3.048 4.064 6.42 9.29 11.23 17.78 17.69 26.80 26.69 42.37
6.35 (250") 3.810 5.080 8.04 11.63 14.06 22.25 22.15 33.54 33.44 53.04
7.62 (300") 4.572 6.096 9.66 13.96 16.88 26.71 26.61 40.27 40.18 63.70
8.89 (350") 5.334 7.112 11.28 16.30 19.71 31.18 31.06 47.01 46.93 74.37
10.16 (400") 6.096 8.128 12.90 18.63 22.54 35.64 35.52 53.74 53.68 85.04
12.70 (500") 7.620 10.160 16.13 23.30 28.19 44.58 44.43 67.21 67.17 106.37
15.24 (600") 9.144 12.192 19.37 27.97 33.85 53.51 53.35 80.68 80.67 127.70
*1 The throw ratio is based on the value during projection of 2.03 m (80") projected image size.
