Items Operation Adjustment
[H]
Press the q button.
Left side will be smaller.
Press the w button.
Right side will be smaller.
[V]
Press the a button.
Upper will be smaller.
Press the s button.
Lower will be smaller.
Setting
[CORNER CORRECTION]
1) Press as to select [SCREEN ADJUSTMENT].
2) Press the <ENTER> button.
f The [SCREEN ADJUSTMENT] screen is displayed.
3) Press as to select [CORNER CORRECTION].
4) Press the <ENTER> button.
f The [CORNER CORRECTION] screen is displayed.
5) Press as to select the item to adjust, then press the <ENTER> button.
f The [CORNER CORRECTION] individual adjustment screen is displayed.
6) Press asqw to adjust.
[CORNER CORRECTION]
[UPPER LEFT] [UPPER RIGHT] [LOWER LEFT] [LOWER RIGHT]
Setting
[CURVED CORRECTION]
1) Press as to select [SCREEN ADJUSTMENT].
2) Press the <ENTER> button.
f The [SCREEN ADJUSTMENT] screen is displayed.
3) Press as to select [CURVED CORRECTION].
4) Press the <ENTER> button.
f The [CURVED CORRECTION] screen is displayed.
5) Press as to select one item to adjust.
[KEYSTONE]
Adjusts when the trapezoid of the projected image is distorted.
[ARC]
Adjusts when the radian of the projected image is distorted.
6) Press the <ENTER> button.
f The [KEYSTONE] or [ARC] individual adjustment screen is displayed.
7) Press asqw to adjust the item.
Chapter 4 Settings - [POSITION] menu
56 -
ENGLISH
