Panasonic PTDZ8700U - DLP PROJECTOR

Technical Information
116
- ENGLISH
Appendix
J
When WEB Control administrator rights password is not set
(Non-protect mode)
<Connection method>
Obtain the IP address and port number (Initial set value = 1024) of the projector and 1 )
make a request for connection to the projector.
You can obtain both IP address and port number from the menu screen of the projector.
IP address : Obtain from MAIN MENU
⇒
[NETWORK]
⇒
[NETWORK STATUS]
Port number : Obtain from MAIN MENU
⇒
[NETWORK]
⇒
[NETWORK CONTROL]
⇒
[COMMAND PORT]
There is a response from the projector.2 )
Response data
Data section Blank Mode
Termination
symbol
“NTCONTROL”
(ASCII string)
‘ ’
0x20
‘0’
0x30
(CR)
0x0d
9 bytes 1 byte 1 byte 1 byte
Mode : 0 = Non-protect mode
<Command transmission method>
Transmit by the following command format.
Transmitted data
Header Data section
Termination
symbol
‘0’
0x30
‘0’
0x30
Control command
(ASCII string)
(CR)
0x0d
1 byte 1 byte Undened length 1 byte
Receive data
Header Data section
Termination
symbol
‘0’
0x30
‘0’
0x30
Control command
(ASCII string)
(CR)
0x0d
1 byte 1 byte Undened length 1 byte
Error response
Error message Termination symbol
“ERR1”
“ERR2”
“ERR3”
“ERR4”
“ERR5”
“ERRA”
Undened control command
Out of parameter range
Busy state or no-acceptable period
Timeout or no-acceptable period
Wrong data length
Password mismatch
(CR)
0x0d
4 bytes 1 byte
