Connecting example : Computers
Note
The DVI-D signal input terminal supports only a single link.
z
For the specications of the RGB signals that can be applied from the PC, refer to “List of compatible signals”.
z
(
Æ
page 122)
If your computer has the resume feature (last memory), the computer may not function properly until the resume capability
z
is disabled.
When the SYNC ON GREEN signal is input, do not input sync signals to the SYNC/HD and VD terminals.
z
When using the DVI-D input, EDID settings may be required for the connected device.
z
(
Æ
page 72)
When using an HDMI cable, check that it is compliant with the HDMI standard. Using a cable that is not compliant with the
z
HDMI standard may result in problems such as the image cutting out or not appearing.
When connecting the 1 080p signal using HDMI, use a cable compliant with 1 080p signal.
It is possible to connect the HDMI input terminal with an external device having a DVI terminal using an HDMI/DVI
z
conversion cable, but with some devices the images may not appear or other problems may occur. (
Æ
page 73)
ComputerComputer
Computer
Control
Computer
Control
Computer
To Next Page
