AMPLIFIER SECTION
RMS power output
THD 10%, both channels driven
both channel driven
(E,EB)
80 W per channel (6
)
(EG)
60 W per channel (6
)
Input sensitivity
AUX
250 mV
Input Impedance
AUX
13 k
FM TUNER SECTION
Frequency range
87.50 - 108.00 MHz (50 kHz
steps)
Sensitivity
1.8
V (IHF)
S/N 26 dB
1.5
V
Antenna terminal(s)
75
(unbalanced)
AM TUNER SECTION
Frequency range
522 - 1629 kHz (9 kHz steps)
Sensitivity
S/N 20 dB (at 999 kHz)
560
V/m
CASSETTE DECK SECTION
Track system
4 track, 2 channel
Heads
Record/playback
Solid permalloy head
Erasure
Double gap ferrite head
Motor
DC servo motor
Recording system
AC bias 100 kHz
Erasing system
AC erase 100 kHz
Tape speed
4.8 cm/s
Frequency response (+3 dB, -6 dB at DECK OUT)
NORMAL (TYPE I)
35 Hz - 14 kHz
S/N
50 dB (A weighted)
Wow and flutter
0.18% (WRMS)
Fast forward and rewind time
Approx. 120 seconds with
C-60 cassette tape
CD SECTION
Sampling frequency
44.1 kHz
Decoding
16 bit linear
Beam source/wave length
Semiconductor laser/780 nm
Number of channels
Stereo
Frequency response
20 Hz - 20 kHz (+1, -2 dB)
Wow and flutter
Below measurable limit
Digital filter
8 fs
D/A converter
MASH (1 bit DAC)
GENERAL
Power supply
(E,EG) AC 230-240V, 50 Hz
(EB) AC 230, 50 Hz
Power consumption
170 W
Power consumption in standby mode
0.4 W
2
