Panasonic SA-AK22 - Cabinet Parts Location

[
]
Ref. No. Part No. Part Name & Description Remarks
358 RAE0152Z-3 TRAVERSE [M]
358-1 SHGD113-1 FLOATING CUSHION [M]
358-2 SNSD38 TRV MOTOR ASSY SCREW [M]
358-3 RAF0150A-4S 50A OPTICAL PICKUP [M]
358-4 RDG0247 DRIVE GEAR [M]
358-5 RDG0248 RELAY GEAR [M]
358-6 RXQ0339 TRAVERSE MOTOR ASSY [M]
358-7 RXQ0304-1 NUT PLATE ASSY [M]
358-8 XQN17+CG5 NUT PLATE ASSY SCREW [M]
358-9 XQS2+A3FZ SPINDLE MOTOR SCREW [M]
358-10 XQS17+A35FZ TRAVERSE MOTOR SCREW [M]
359 RME0142 FLOATING SPRING A [M]
360 RME0109 FLOATING SPRING B [M]
361 RMR1124-K1 TRAVERSE CHASSIS [M]
362 RMS0632 TRAVERSE PIN [M]
363 XTN2+6G SCREW [M]
369 RMX0141 PUSH SPACER [M]
370 RMQ0749 UPPER SPINDLE [M]
371 RHM0001 MAGNET [M]
372 RMX0140 DISC SPACER [M]
373 RME0261 FRONT LOCK SPRING [M]
374 RMQ0742 SPINDLE BASE [M]
20.3. Cabinet
20.3.1. Cabinet Parts Location
60
