Ref. No. Part No. Part Name & Description Remarks
TRAVERSE DECK
301 RML0517 TIMING LEVER [M]
302 RML0516 PLUNGER LEVER [M]
303 RMB0551 UPPER SPINDLE SPRING [M]
304 RMQ0744 LOWER HOOK [M]
305 RDV0056 BELT [M]
306 RML0525 FRONT LOCK LEVER [M]
307 RML0526 DISC LEVER [M]
308 RDG0424 DRIVE GEAR [M]
309 RDG0425 CHANGE GEAR [M]
310 RDG0427 TRAVERSE CAM GEAR [M]
311 RDG0428 TRAVERSE RELAY GEAR [M]
312 RDG0426 UP/DOWN GEAR [M]
313 RDG0429 PULLEY GEAR [M]
314 RMB0549-1 CHANGE GEAR SPRING [M]
315 RMQ0748 PITCH PLATE [M]
316 RMB0553 PUSH SPRING [M]
317 RML0530 ASSIST LEVER [M]
318 RML0518 CONNECTION LEVER [M]
319 RMM0201 SLIDE PLATE 1 [M]
320 RME0258 REAR LOCK SPRING [M]
321 RML0521 REAR LOCK [M]
322 RME0257 TRAY LOCK LEVER SPRI [M]
323 RML0520 TRAY LOCK [M]
324 RMM0202 SLIDE PLATE 2 [M]
325 XTB3+10J SCREW [M]
326 RMR0334 FIXED PLATE [M]
327 RMR0624-W2 CLAMPER [M]
328 RMB0561 ASSIST LEVER SPRING [M]
329 RMR1121-K MECHA COVER [M]
330 RMA1110-2 TRAY ANGLE [M]
331 RMR1122-H1 TRAY BASE [M]
332 RMM0204 CARRIER [M]
333 RMM0203 DRIVE RACK [M]
334 RDG0432 SPEED UP GEAR [M]
335 RML0524 SLIDE LOCK [M]
336 RML0523 CARRIER LOCK [M]
337 RME0260-1 SLIDE LOCK SPRING [M]
338 RMR1123-H TRAY [M]
339 RXQ0595 MOTOR SUB ASS’Y [M]
341 RSJ0003 SOLENOLD ASS’Y [M]
343 RMA1106 UPPER PLATE [M]
344 RML0519 8CD LEVER [M]
345 RFKNAAK27GCS MECHA BASE ASS’Y [M]
346 RML0522 TURNING STOPPER [M]
347 RMQ0745 LOWER SPINDLE [M]
348 RMQ0746 UP/DOWN BASE [M]
349 RMB0550 LOWER SPINDLE SPRING [M]
350 RMQ0747 UPPER HOOK [M]
351 RME0263 CLICK SPRING [M]
352 RMQ0743 SPINDLE SHAFT [M]
353 RMB0552 CUSHION SPRING [M]
354 RDG0430 RELAY GEAR ‘A’ [M]
355 RDG0431 RELAY GEAR ‘B’ [M]
356 RME0262 DISK LEVER SP. [M]
357 RMA1105 SUPPORT PLATE [M]
59
