Panasonic SA-AK22 - Page 24

Step 1 Place the traverse unit as shown.
Step 2 Press in the lever shaft in the direction of arrow 1 as shown and push the traverse unit into the
position in the direction of arrow 2.
Step 3 Pull the stopper in the direction of arrow 1 and release the lever in the direction of arrow 2 as
shown.
Step 4 Pull out the tray half way and push it back fully.
24
