Notes:
- Important safety notice:
Components identified by
mark have special characteristics
important for safety.
Furthermore, special parts which have purposes of fire-retardent
(resistors), high-quality sound (capacitors), low noise (resistors), etc
are used.
When replacing any of these components, be sure to use only
manufacturer’s specified parts shown in the parts list.
- The parenthesized indications in the Remarks columns specify the
areas or colour. (Refer to the cover page for area or colour)
Parts without these indications can be used for all areas.
- Warning: This product uses a laser diode. Refer to caution statements
on “Precaution of Laser Diode”.
ACHTUNG:
- Die Lasereinheit nicht zerlegen.
- Die Lasereinheit darf nur gegen eine vom Hertsteller spezifizierte
Einheit ausgetauscht werden.
- Capacitor values are in microfarads (
F) unless specified otherwise, P
= Pico-farads (pF), F= Farads.
- Resistance values are in ohms, unless specified otherwise, 1K=1,000
(OHM).
- The marking (RTL) indicates that the Retention Time is limited for this
items. After the discontinuation of this assembly in production, the
item will continue to be available for a specific period of time. The
retention period of a availability is dependent on the type of assembly,
and in accordance with the laws governing part and product retention.
After the end of this period, the assembly will no longer be available.
- [M] Indicates in the Remarks columns indicates parts supplied by
MESA.
- The “(SF)” mark denotes the standard part.
- Remote Control Unit: Supply period for three years from terminal of
production.
- Reference for O/I book languages are as follows:
