Ref. No. Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 REEX0129 14P FFC [M]
2 REEX0101 28P FFC [M]
3 REEX0127 20P FFC [M]
4 REEX0130 19P FFC [M]
5 RGB0113-N PANA BADGE [M]
6 RGKX0070-S CD LID [M]
7 RGKX0071-AB CD ORNAMENT [MAVD]
8 RGLX0028-Q POWER LIGHTING CHIP [M]
9 RGLX0030-Q DISC LIGHT CHIP [M]
10 RGPX0038E-SL FRONT PANEL [MAVD]
11 RGRX0017G-AB REAR PANEL EG E
11 RGRX0017G-DB REAR PANEL EB
12 RGUX0368A-SB POWER BUTTON [MAVD]
13 RGUX0369Z-S CD EJECT BUTTON [MAVD]
14 RGUX0371-SB DISC BUTTON [MAVD]
15 RGUX0372-SB DECK BUTTON [MAVD]
16 RGUX0378Z-S DECK EJECT BUTTON L [MAVD]
17 RGUX0379Z-S DECK EJECT BUTTON R [MAVD]
18 RGUX0397Z-S DISPLAY BUTTON [MAVD]
19 RGUX0400-SB AUXILIARY BUTTON [MAVD]
20 RGUX0411-Q AMAZING BUTTON [M]
22 RGUX0412-SB FUNCTION BUTTON [MAVD]
23 RGWX0055-S VOLUME KNOB [M]
24 RHD30002-H SCREW [M]
25 RKA0059-K LEG RUBBER [M]
26 RKFX0083-SB CASS LID (L) [MAVD]
27 RKFX0084-SB CASS LID (R) [MAVD]
28 RKFX0085-KB CASS. HOLDER (L) [MAVD]
29 RKFX0086-KB CASS. HOLDER (R) [MAVD]
30 RKMX0057-S TOP CABINET (BENT) [M]
31 RKWX0148-AB CASS WIN (L) [MAVD]
32 RKWX0149-AB CASS WIN (R) [MAVD]
34 RMBX0016-1 CASS. OPEN SPRING [M]
35 RMKX0053 BOTTOM CHASSIS [MAVD]
36 RMKX0044-B INNER CHASSIS [MAVD]
37 RMKX0045-B T-BRACKET [MAVD]
38 RMNX0039-HB SUB-TRANS SUPPORT [MAVD]
39 RMNX0048 HOLDER [M]
41 RSCX0052 SHIELD PLATE HEAD [M]
42 RSCX0058 DECK SHIELD PLATE [M]
43 RUS757ZAA CASSETTE HALF SPRING [M]
44 RXGX0001 DAMPER GEAR [M]
45 RXXX0021 HEAT SINK UNIT [M]
46 RYQX0040-SL CONTROL BUTTON UNIT [MAVD]
47 RYQX0042-S JOY JOG UNIT [M]
48 RKWX0157-A FL ORNAMENT [M]
49 SHE187-5 PCB SUPPORT (NO PIN) [M]
50 XTB3+10J SCREW [M]
51 XTB3+10JFZ SCREW [M]
52 XTB3+20J SCREW [M]
53 XTBS26+10J SCREW [M]
54 XTBS3+8JFZ1 SCREW [M]
55 XTW3+15T SCREW [M]
56 XTW3+8T SCREW [M]
57 RKWX0156 FL FILTER [M]
