1. Disassembly of Side Panel L & R
2. Disassembly of Top Cabinet
3. Disassembly of Deck Mechanism P.C.B and Tape Eject
P.C.B.
4. Disassembly of Headphone P.C.B.
5. Disassembly of Front Panel
6. Disassembly of Panel P.C.B.
7. Disassembly of Rear Cabinet
8. Disassembly of Tuner Pack
9. Disassembly of Main P.C.B.
10. Disassembly of Power P.C.B.
11. Disassembly of Speaker Terminal P.C.B.
12. Disassembly of Transformer P.C.B.
13. Disassembly of CD Mechanism
Service tools
Extension cable
(Main P.C.B. and Speaker
Terminal P.C.B.)
RFKPM21
11 Service Positions
11.1. Checking procedure
Note:
For the disassembling procedure, see the section 10.
11.2. Checking the major P.C.B.
29
SA-PM21PC
