Ref. No. Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 RDG0357 DAMPER GEAR [M]
2 REEV0033 12P FFC (PANEL-MAIN) [M]
3 REEV0034 17P FFC (MAIN-CR120) [M]
4 REEV0035 19P (DECK-MAIN) [M]
5 RGKV0087-S CD LID [M]
6 RGLV0045-Q LIGHTING TIP [M]
7 RGUV0102-S MP3 CTRL BUTTON [M]
8 RGUV0103-S SUB CTRL BUTTON [M]
9 RGUV0105-S MAIN FUNCTION BUTTON [M]
10 RGUV0106-S POWER BUTTON [M]
11 RGUV0107-S RECORD BUTTON [M]
12 RGUV0108-S CASS EJECT BUTTON [M]
13 RGWV0004-S VOLUME KNOB [M]
14 RHD26046-L SCREW [M]
15 RHD30007-1SJ SCREW [M]
16 RHGV0008 LEG CUSHION [M]
17 RKF0479-1H1 CASS HOLDER [M]
18 RKFV0001A-S CASS LID [M]
19 RKM0445A-1S SIDE PANEL (L) [M]
20 RKM0446A-1S SIDE PANEL (R) [M]
21 RKMV0003A-S TOP CABINET [M]
22 RKMV0043A-S1 FRONT PANEL [M]
23 RFKHAPM21PCS REAR CABINET ASS’Y [M]
24 RKWV0044A-R1 FL WINDOW [M]
25 RMAV0001 MAIN PCB SUPPORT [M]
26 RMB0617 CASS OPEN SPRING [M]
27 RMK0498A BOTTOM CHASSIS [M]
28 RMNV0017 FL HOLDER [M]
29 RSCV0051 REAR SHIELD [M]
30 RUS757ZAA CASS HALF SPRING [M]
31 RXXV0036 HEAT SINK UNIT [M]
32 SHE187-4J POWER PCB SUPPORT [M]
33 XTB3+10JFJK SCREW [M]
34 XTB3+20JFJK SCREW [M]
35 XTB3+8JFJK SCREW [M]
36 XTB3+8JFJ SCREW [M]
37 XTV3+10GFJ-M SCREW [M]
38 XTV3+8FFJ SCREW [M]
24.3.2. Cabinet Parts List
