24.3 Cabinet Part List
24.3.1 Cabinet Parts Location
24.3.2 Cabinet Parts List
361 RMQ1061 TG.PLATE [M]
362 RMR0334 FIXTURE [M]
363 RMR0624-W5 CLAMPER [M]
364 RMR1407A-H1 TRAY NO. 1 [M]
365 RMR1407B-H1 TRAY NO. 2 [M]
366 RMR1407C-H1 TRAY NO. 3 [M]
367 RMR1407D-H1 TRAY NO. 4 [M]
368 RMR1407E-H1 TRAY NO. 5 [M]
369 RFKNAPM77MDS MECHA BASE ASS’Y [M]
370 RMR1427-X MIDDLE CHASSIS [M]
371 RMS0757-1 FIXED PIN [M]
375 RMS0762 TRAY GEAR SHAFT [M]
376 RXG0053 TRAY DRIVE GEAR ASSY [M]
377 RXQ0999 OPU UNIT [M]
378 RXQ0803 LOADING MOTOR ASS’Y [M]
379 RXQ0804 UD MOTOR ASS’Y [M]
380 XTB3+10J SCREW [M]
381 XTN2+6G SCREW [M]
382 RMC0472 TRAY SPRING [M]
383 XTBS26+8J SCREW [M]
Ref. No. Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 REEV0026 21P FFC [M]
2 REEV0027 26P FFC (PANEL-MAIN) [M]
3 REEV0039 17P FFC (CR16-MAIN) [M]
4 REEX0166 14P FFC WIRE [M]
5 REM0094A COOLING FAN [M]
6 RGK1750-S VOLUME RING [M]
7 RYPV0034A-S FRONT PANEL UNIT [M]
7-1 RYQV0014A-S CD LID UNIT [M]
7-2 RYQV0015-S BUTTON UNIT [M]
7-3 RHGV0008 LEG CUSHION [M]
7-4 RGUV0063-S CD/MAIN SELECTION BT [M]
7-5 RGK1756-A M/FUNCTION BTN ORN. [M]
8 RGL0660-Q1 VOLUME RING LIGHT [M]
9 RFKHAPM29PCS REAR PANEL ASS’Y [M]PC
9 RFKHAPM29P-S REAR PANEL ASS’Y [M]P
10 RGU2280-S CASS EJECT BUTTON [M]
11 RGW0406-S VOLUME KNOB [M]
12 RHD30007-K1 SCREW [M]
