Panasonic SA-PM29P - Disassembly of Main P.C.B; Disassembly of Transformer P.C.B

Step 2 : Release the connector CN303.
11.8 Disassembly of Main P.C.B
z Follow the (Step 1) - (Step 6) of Item 11.2.
z Follow the (Step 1) - (Step 3) of Item 11.3.
z Follow the (Step 1) - (Step 4) of Item 11.5.
z Follow the (Step 1) - (Step 2) of Item 11.7.
Step 1 : Release all the connector CN305 & CN306.
Step 2 : Detach FFC Board (CN301 and CN302).
Step 3 : Lift up the Main P.C.B as arrow shown.
11.9 Disassembly of Transformer P.C.B
z Follow the (Step 1) - (Step 6) of Item 11.2.
z Follow the (Step 1) - (Step 3) of Item 11.3.
z Follow the (Step 1) - (Step 4) of Item 11.5.
z Follow the (Step 1) - (Step 2) of Item 11.7.
