Panasonic SA-PM29P - Disassembly of Power P.C.B

z Follow the (Step 1) - (Step 3) of Item 11.8.
Step 1 : Remove all the screws.
Step 2 : Release the connector CN506.
11.10 Disassembly of Speaker Terminal P.C.B
z Follow the (Step 1) - (Step 6) of Item 11.2.
z Follow the (Step 1) - (Step 3) of Item 11.3.
z Follow the (Step 1) - (Step 4) of Item 11.5.
z Follow the (Step 1) - (Step 2) of Item 11.7.
z Follow the (Step 1) - (Step 3) of Item 11.8.
z Follow the (Step 1) - (Step 2) of Item 11.9.
Step 1 : Release the connector CN504.
Step 2 : Remove the screw.
Step 3 : Remove the Speaker Terminal as arrow shown.
11.11 Disassembly of Power P.C.B
z Follow the (Step 1) - (Step 6) of Item 11.2.
z Follow the (Step 1) - (Step 3) of Item 11.3.
z Follow the (Step 1) - (Step 4) of Item 11.5.
z Follow the (Step 1) - (Step 2) of Item 11.7.
z Follow the (Step 1) - (Step 3) of Item 11.8.
z Follow the (Step 1) - (Step 2) of Item 11.9.
