11.22 CR16 MECHANISM ASSEMBLY PROCEDURE
The following specified greases and/or oil must be applied when some specific parts are changed.
1. Floil grease (VFK1298) : The floil grease must be applied to tray, tray (L) and tray (R).
2. Hanarl oil (VFK1700) : The hanarl oil must be applied to any parts with grease other than the said parts.
z Follow the (Step 1) - (Step 6) of Item 11.2.
z Follow the (Step 1) - (Step 3) of Item 11.3.
z Follow the (Step 1) - (Step 4) of Item 11.5.
z Follow the (Step 1) - (Step 2) of Item 11.7.
z Follow the (Step 1) - (Step 3) of Item 11.8.
z Follow the (Step 1) - (Step 2) of Item 11.9.
