Panasonic SA-PMX150 - Protection Circuitry; Caution for Fuse Replacement; Safety Part Information

4
1.3. Protection Circuitry
The protection circuitry may have operated if either of the following conditions are noticed:
• No sound is heard when the power is turned on.
• Sound stops during a performance.
The function of this circuitry is to prevent circuitry damage if, for example, the positive and negative speaker connection wires are
"shorted", or if speaker systems with an impedance less than the indicated rated impedance of the amplifier are used.
If this occurs, follow the procedure outlines below:
1. Turn off the power.
2. Determine the cause of the problem and correct it.
3. Turn on the power once again after one minute.
Note:
When the protection circuitry functions, the unit will not operate unless the power is first turned off and then on again.
1.4. Caution For Fuse Replacement
1.5. Safety Part Information
Safety Parts List:
There are special components used in this equipment which are important for safety.
These parts are marked by in the Schematic Diagrams, Exploded View & Replacement Parts List. It is essential that these
critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire or other hazards. Do not modify the
original design without permission of manufacturer.
Safety Ref. No. Part No. Part Name & Description Remarks
12 RGR0474M-A REAR CABINET 150PCS
12 RGR0474M-B REAR CABINET 150EGS
12 RGR0474N-A REAR CABINET 152EGS
48 RFKKMX100EGS TOP AL ORNAMENT ASS'Y
301 TXQ0011 TRAVERSE ASS’Y (E.S.D)
A2 K2CB2YY00065 AC CORD 150PCS
A2 K2CQ2YY00107 AC CORD 150EGS, 152EGS
A3 TQBJ0992 O/I BOOK (En) 150EGS
A3 TQBJ0993 O/I BOOK (Ge/It/Fr/Du) 150EGS, 152EGS
A3 TQBJ0994 O/I BOOK (Da/Sw/Fi) 150EGS, 152EGS
A3 TQBJ0995 O/I BOOK (Po/Cz/Sp) 150EGS
A3 TQBJ0996 O/I BOOK (En/Cf) 150PCS
PCB6 TNPA6426 SMPS P.C.B (RTL) 150EGS,152EGS
PCB6 TNPA6426AB SMPS P.C.B (RTL) 150PCS
C5700 F1BAF102A216 1000pF AC250 <= Vac <315
C5701 F0CAF104A218 0.1uF AC250 <= Vac <315
C5702 F0CAF104A218 0.1uF AC250 <= Vac <315
C5704 F1BAF4710005 470pF AC250 <= Vac <315
C5705 F1BAF4710005 470pF AC250 <= Vac <315
C5706 F1BAF102A216 1000pF AC250 <= Vac <315
DZ5701 D4EAY5110006 DIODE
L5701 G0B103G00023 INDUCTOR
L5702 G0B103G00023 INDUCTOR
T5700 G4DYZ0000085 SWITCHING TRANSFORMER
PC5721 B3PBA0000579 PHOTO COUPLER
PC5723 B3PBA0000579 PHOTO COUPLER
PC5724 B3PBA0000579 PHOTO COUPLER
P5701 K2AA2B000011 AC INLET 150EGS, 152EGS
P5701 K2AB2B000007 AC INLET 150PCS
F1 K5G312YA0159 F1
R5700 ERJ12YJ125U 1.2M 1/2W
R5701 ERJ12YJ125U 1.2M 1/2W
