Panasonic SA-PMX150 - Page 76

76
CONNECTORS
CN51 K1MY13BA0079 13P CONNECTOR 1
RESISTORS
R51 D0GB222JA065 2.2K 1/10W 1
R52 D0GB561JA065 560 1/10W 1
R55 D0GA221JA023 220 1/16W 1
R56 D0GB221JA065 220 1/10W 1
R57 D0GA102JA023 1K 1/16W 1
R59 D0GB222JA065 2.2K 1/10W 1
R60 D0GB331JA065 330 1/10W 1
R64 D0GBR00J0004 0 1/10W 1
R67 D0GBR00J0004 0 1/10W 1
R74 D0GBR00J0004 0 1/10W 1 150EGS
R76 D0GBR00J0004 0 1/10W 1 150PCS
PRINTED CIRCUIT
BOARDS
PCB3 TNPA6415AG BLUETOOTH P.C.B 1 150EGS
PCB3 TNPA6415AH BLUETOOTH P.C.B 1 150PCS
PCB3 TNPA6415AL BLUETOOTH P.C.B 1 152EGS
PRINTED CIRCUIT
BOARDS
PCB4 TNPA6416AG USB P.C.B 1 (RTL)
150EGS
PCB4 TNPA6416AH USB P.C.B 1 (RTL)
150PCS
PCB4 TNPA6416AL USB P.C.B 1 (RTL)
152EGS
CONNECTORS
CN6100 K1KA07BA0047 7P CONNECTOR 1
CN6101 K1FY104A0015 USB CONNECTOR 1
RESISTORS
R6100 D0GAR00J0005 0 1/16W 1
R6101 D0GAR00J0005 0 1/16W 1
PRINTED CIRCUIT
BOARDS
PCB5 TNPA6421AG ALLPLAY ANTENNA
P.C.B
1 150EGS
PCB5 TNPA6421AH ALLPLAY ANTENNA
P.C.B
1 150PCS
PCB5 TNPA6421AL ALLPLAY ANTENNA
P.C.B
1 152EGS
PRINTED CIRCUIT
BOARDS
PCB6 TNPA6426 SMPS P.C.B 1 (RTL)
150EGS,
152EGS
PCB6 TNPA6426AB SMPS P.C.B 1 (RTL)
150PCS
INTEGRATED CIR-
CUITS
IC1111 C0DBBYY00062 IC 1
IC2900 C0DBAYY01282 IC 1
IC5801 C0DAAYY00072 IC 1
IC5802 C0DAAYY00072 IC 1
CAPACITORS
C2902 F1H1H103B047 0.01uF 50V 1
C2903 F1H1H682B047 6800pF 50V 1
Safety Ref. No. Part No. Part Name &
Description
Qty Remarks
C2905 F2A1H101A147 100uF 50V 1
C2906 F2A1V560B146 56uF 35V 1
C5700 F1BAF102A216 1000pF AC250
<= Vac <315
1
C5701 F0CAF104A218 0.1uF AC250
<= Vac <315
1
C5702 F0CAF104A218 0.1uF AC250
<= Vac <315
1
C5704 F1BAF4710005 470pF AC250
<= Vac <315
1
C5705 F1BAF4710005 470pF AC250
<= Vac <315
1
C5706 F1BAF102A216 1000pF AC250
<= Vac <315
1
C5708 F1B3D102A132 1000pF 2000V 1
C5720 F2A2G820A354 82uF 400V 1 150EGS,
152EGS
C5720 F2B2D1810007 180uF 200V 1 150PCS
C5721 F0C2K103A053 0.01uF 800V 1
C5722 F1H1H101B052 100pF 50V 1
C5723 F2A1H100B411 10uF 50V 1
C5724 F1B3D101A132 100pF 2000V 1
C5725 F1H1H681B047 680pF 50V 1
C5727 F1H1H100B051 10pF 50V 1
C5728 F1H1H102B047 1000pF 50V 1
C5729 F2A1H100B411 10uF 50V 1
C5730 F1H1H104B047 0.1uF 50V 1
C5800 F1H1H101B052 100pF 50V 1
C5801 F1J1H105A918 1uF 50V 1
C5802 F2A1V4710074 470uF 35V 1
C5803 F2A1V4710074 470uF 35V 1
C5805 F1H1H104B047 0.1uF 50V 1
C5807 F1H1H102B047 1000pF 50V 1
C5808 F2A0J4700054 47uF 6.3V 1
C5810 F1H1H104B047 0.1uF 50V 1
C5811 F2A1E3320065 3300uF 25V 1
C5812 F1H1H102B047 1000pF 50V 1
C5829 F1H1H104B047 0.1uF 50V 1
C5841 F1H1H102B047 1000pF 50V 1
C5842 F1H1H104B047 0.1uF 50V 1
C5843 F1H1H104B047 0.1uF 50V 1
C5844 F1H1H104B047 0.1uF 50V 1
C5845 F1H1H102B052 1000pF 50V 1
DIODE
D2900 B0JCPD000025 DIODE 1
D5701 B0EDNR000001 DIODE 1
D5702 B0EAKT000063 DIODE 1
D5703 DZ2J200M0L DIODE 1
D5704 DZ2J200M0L DIODE 1
D5705 B0EAMM000057 DIODE 1
D5707 DA2J10100L DIODE 1
D5708 B0JCPD000039 DIODE 1
D5709 B0EAKT000063 DIODE 1
D5710 DZ2J075M0L DIODE 1
D5711 DA2J10100L DIODE 1
D5712 DA2J10100L DIODE 1
D5801 B0ADRL000001 DIODE 1
D5802 B0HBSM000054 DIODE 1
D5803 DA2J10100L DIODE 1
D5804 DA2J10100L DIODE 1
D5841 DZ2J075M0L DIODE 1
DZ5701 D4EAY5110006 DIODE 1
INDUCTORS
L2900 G0A330ZA0045 INDUCTOR 1
LB2901 J0JKB0000020 INDUCTOR 1
L5701 G0B103G00023 INDUCTOR 1
L5702 G0B103G00023 INDUCTOR 1
L5801 G0A330ZA0045 INDUCTOR 1
TRANSISTORS
Safety Ref. No. Part No. Part Name &
Description
Qty Remarks
